200155-13-05 | Bently Nevada 100 mV/g Low Frequency Accelerometer

Introduction to the 200155-13-05 Bently Nevada Accelerometer

When slow rotating shafts demand accurate vibration data, the 200155-13-05 provides reliable low-frequency measurements. This Bently Nevada Low Frequency Trendmaster Pro Accelerometer is engineered for fin-fan and similar applications. It offers a sensitivity of 10.2 mV/(m/s²) (100 mV/g) at 80 Hz. The device operates with an excitation voltage of 4.7 to 5.5 Vdc. Its compact design ensures easy integration into existing systems.

Key Features and Technical Specifications of 200155-13-05

• Sensitivity: 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, ±12% tolerance.
• Measurement range: ±196 m/s² (±20 g) peak.
• Frequency range: 1.5 to 10,000 Hz (90 to 600,000 cpm) referenced to 80 Hz.
• Mounted resonant frequency: >20 kHz (>1200 kcpm).
• Amplitude linearity: ±2% (1 to 10 g pk).
• Transverse sensitivity: ≤7%.
• Settling time: ≤2000 ms (within 5% of bias).
• Output bias voltage: +2.5 ± 0.23 Vdc.
• Quiescent current: <800 µA.
• Axial shock limit: 49,050 m/s² pk (5,000 g pk).

The unique low-frequency performance of the 200155-13-05 enables accurate vibration monitoring down to 1.5 Hz. This capability is essential for detecting early bearing wear in slow-speed machinery.

Applications and Use Cases for 200155-13-05

The 200155-13-05 excels in fin-fan and slow rotating shaft applications. It monitors vibration on cooling tower fans, agitators, and other low-speed equipment. Its hermetically sealed design withstands harsh industrial environments. The device operates reliably in temperatures from -40 °C to +105 °C. This makes it suitable for outdoor and process-critical installations.

Installation and Mounting Guidance

Mount the 200155-13-05 using the 3/8-24 female thread. Apply a mounting torque of 2.7 to 6.8 N·m (2 to 5 ft·lbf). The mounting stud option (13) is a 3/8-24 to 5/16-18 UNC, 3/4 inch hex stud. Ensure the mounting surface is clean and flat for optimal coupling. Allow 24 hours cure time for any adhesive used. Always follow the manufacturer's installation manual for best results.

Maintenance and Reliability Tips

Regular inspection of the 200155-13-05 ensures long-term reliability. Check the cable and connector for damage periodically. The 316L stainless steel housing resists corrosion in demanding environments. With a hermetic seal rating of 5×10⁻⁸ atm·cc/s maximum, the sensor maintains its integrity. This reduces the need for frequent recalibration and extends service life.

Compatibility and Integration

The 200155-13-05 works with the ProTIM Option Low Frequency Acceleration-to-Velocity channel type (-05). It is designed for use with Bently Nevada monitoring systems. The device outputs a positive signal (SIG+ positive with respect to SIG-) for acceleration from base to connector. This simplifies integration into existing vibration monitoring architectures.

Frequently Asked Questions about 200155-13-05

Q: What is the sensitivity of the 200155-13-05?

A: The sensitivity is 10.2 mV/(m/s²) (100 mV/g) at 80 Hz, with a tolerance of ±12%.

Q: What is the measurement range of this accelerometer?

A: The measurement range is ±196 m/s² (±20 g) peak.

Q: What temperature range can the 200155-13-05 operate in?

A: It operates from -40 °C to +105 °C (-40 °F to +221 °F).

Q: What mounting thread does the 200155-13-05 use?

A: It uses a 3/8-24 female thread, with a mounting stud option of 3/8-24 to 5/16-18 UNC.

Q: What approvals does the 200155-13-05 have?

A: It has multiple approvals including CSA, ATEX, and IECEx.

Product Support and Availability

The 200155-13-05 is available from Petro Auto Tech. Please verify current lifecycle status and availability before ordering. Contact Petro Auto Tech for pricing and delivery options.
