Allen-Bradley 1734-IA2 Digital AC Input Module 2-Channel

Product Overview

The Allen-Bradley 1734-IA2 is a digital AC input module from the POINT I/O series. It features two input channels for 120 Volts AC signals. Each channel has a status indicator for easy troubleshooting. The module works with ControlNet, DeviceNet, and EtherNet/IP networks. Its compact form factor saves panel space. You can install it horizontally or vertically on a DIN rail. This module suits a wide range of industrial applications. It integrates seamlessly with Rockwell Automation PLCs.

Application Scenarios

Use this module in automotive, packaging, and material handling systems. It senses 120V AC signals from push buttons, limit switches, and sensors. The two channels handle simple on/off inputs for discrete control. It works well with CompactLogix and ControlLogix controllers. The module operates in harsh environments with reliable performance. It supports both new installations and upgrades of existing systems.

Technical Specifications

• Input voltage: 120 Volts AC nominal (85 to 132 VAC)
• Frequency: 47 to 63 Hertz
• Inputs: 2 channels, 1 group of 2
• POINTBus current: 75 mA at 5 VDC maximum
• Power dissipation: 0.35 Watts at 132 VAC
• Thermal dissipation: 1.19 BTU/hour at 132 VAC
• Isolation voltage: 240 VAC continuous; tested 3250 VDC for 60 seconds
• Input impedance: 10.6 kiloohms
• Dimensions: 56.0 x 12.0 x 75.5 mm
• Weight: 30.9 grams (1.09 ounces)
• Enclosure: Open style

Installation & Maintenance Guide

Mount the 1734-IA2 on a standard DIN rail. Connect the POINTBus cable to the backplane. Wire the 120V AC field inputs to the terminal block. Use the key switch to set the node address. Power up the system and verify input status via LEDs. The module requires no routine maintenance. Keep the area clean and dry. Check connections periodically for tightness.

Packing List

• 1x 1734-IA2 input module
• Installation manual
