200350-11-00-00 | Bently Nevada 100 mV/g Accelerometer

Introduction to the Bently Nevada 200350-11-00-00

When machinery vibration threatens uptime, the 200350-11-00-00 from Bently Nevada provides precise measurement. This accelerometer is part of the 200350 series. It is engineered for harsh industrial environments. With a sensitivity of 100 mV/g, it captures subtle vibrations. The unit operates reliably in extreme conditions.

Key Features and Technical Specs

The 200350-11-00-00 offers several standout specifications. Each value is taken directly from the datasheet.

• Sensitivity: 100 mV/g ±20% (10.2 mV/m/s² ±20%)
• Frequency Range: 30 to 600,000 cpm (0.5 to 10,000 Hz) at ±3 dB
• Measurement Range: ±50 g
• Transverse Sensitivity: ≤7%
• Amplitude Linearity: ±1%
• Mounted Resonant Frequency: 1500 kcpm (25 kHz)
• Broadband Electrical Noise (1-10 kHz): 350 μg (3,434 μm/s²)
• Output Bias Voltage: 8 to 12 VDC
• Excitation Voltage: 18 to 28 VDC
• Constant Current Excitation: 2 to 20 mA
• Settling Time (within 1% of bias): 2.0 sec
• Output Impedance: <150 ohms
• Discharge Time Constant: ≥0.3 sec
• Electrical Isolation (Case): >108 ohms
• Operating Temperature Range: -65°F to +250°F (-54°C to +121°C)
• Shock Survivability: 5000 g pk
• Relative Humidity: 100% relative, condensing, non-submerged
• Enclosure Rating: IP68
• Mounting Thread: 1/4-28 Female
• Mounting Torque (Maximum): 2 to 5 ft-lb (2.7 to 6.8 N-m)
• Sensing Element: Ceramic
• Sensing Geometry: Shear
• Housing Material: Stainless Steel
• Sealing: Welded Hermetic
• Electrical Connector: 2-Pin Mil-C-5015
• Electrical Connection Position: Top
• Weight: 0.051 kg

The IP68 rating is a key advantage. It ensures protection against dust and prolonged immersion. This makes the 200350-11-00-00 ideal for wet or dirty environments.

Applications and Use Cases

This accelerometer suits rotating machinery monitoring. It works well in pumps, fans, and compressors. The wide frequency range captures both low-speed and high-speed vibrations. In addition, the ceramic shear sensing element provides stable measurements over time. Consequently, maintenance teams can detect early bearing wear or imbalance.

Installation and Setup

Mount the 200350-11-00-00 using the M6x1 adhesive stud mount. Apply a mounting torque between 2 and 5 ft-lb (2.7 to 6.8 N-m). Ensure the mounting surface is clean and flat. Then connect the 2-pin Mil-C-5015 connector. Finally, verify the output bias voltage is between 8 and 12 VDC before operation.

Maintenance and Reliability

Regular inspection of the cable and connector is recommended. Check for signs of wear or corrosion. The welded hermetic seal prevents moisture ingress. As a result, the unit maintains performance in condensing humidity. For long-term reliability, follow the manufacturer's guidelines.

Frequently Asked Questions

What is the sensitivity of the 200350-11-00-00?

The sensitivity is 100 mV/g ±20% (10.2 mV/m/s² ±20%).

What is the operating temperature range?

The range is -65°F to +250°F (-54°C to +121°C).

Is the accelerometer suitable for wet environments?

Yes, it has an IP68 enclosure rating and can handle 100% condensing humidity.

What type of mounting stud does it use?

It uses an M6x1 adhesive stud mount.

What is the output impedance?

The output impedance is less than 150 ohms.

Product Support and Availability

The 200350-11-00-00 is available from Petro Auto Tech. Please verify current lifecycle status and availability before ordering. Our team can assist with any technical questions.
