200350-13-00-00 | Bently Nevada 100 mV/g Accelerometer

Introduction to the 200350-13-00-00

When machinery vibration threatens uptime, the 200350-13-00-00 provides reliable data for condition monitoring. This Bently Nevada accelerometer is part of the 200350 series and offers a sensitivity of 100 mV/g ±20%. It operates across a wide frequency range of 30-600,000 cpm (0.5-10,000 Hz).

Key Features and Technical Specifications

• Sensitivity: 100 mV/g ±20% (10.2 mV/m/s² ±20%)
• Measurement range: ±50 g
• Frequency response: 30-600,000 cpm (0.5-10,000 Hz) ±3 dB
• Output bias voltage: 8 to 12 VDC
• Excitation voltage: 18 to 28 VDC
• Constant current excitation: 2 to 20 mA
• Operating temperature: -65°F to +250°F (-54°C to +121°C)
• Enclosure rating: IP68
• Housing material: stainless steel
• Weight: 0.051 kg

A standout spec is the IP68 enclosure rating. This means the 200350-13-00-00 withstands continuous immersion in water. It suits washdown environments and outdoor installations.

Applications and Use Cases

This accelerometer excels in rotating machinery monitoring. For example, it detects bearing faults in pumps and motors. Its wide frequency range captures both low-speed and high-speed vibrations. The stainless steel housing resists corrosion in chemical plants. Additionally, the IP68 rating allows use in submersible applications.

Installation and Setup

Mount the 200350-13-00-00 using the 1/4-28 female thread. Apply a mounting torque of 2 to 5 ft-lb (2.7 to 6.8 N-m). The magnetic base kit (option 13) simplifies temporary installations. Connect via the 2-pin Mil-C-5015 connector located on top. Ensure the excitation voltage stays between 18 and 28 VDC.

Maintenance and Reliability

Inspect the accelerometer periodically for physical damage. Check the cable and connector for wear. The welded hermetic seal prevents moisture ingress. With proper care, the 200350-13-00-00 delivers long service life. This reduces replacement costs and unplanned downtime.

Compatibility and Integration

The 200350-13-00-00 integrates with most vibration monitoring systems. It requires a constant current excitation of 2 to 20 mA. The output bias voltage of 8 to 12 VDC is standard for industrial data collectors. Use it with Bently Nevada monitors or third-party systems.

Frequently Asked Questions

Q: What is the sensitivity of the 200350-13-00-00?

A: The sensitivity is 100 mV/g ±20% (10.2 mV/m/s² ±20%).

Q: What is the operating temperature range?

A: It operates from -65°F to +250°F (-54°C to +121°C).

Q: Is the 200350-13-00-00 suitable for wet environments?

A: Yes, its IP68 rating allows continuous immersion in water.

Q: What mounting thread does it use?

A: It uses a 1/4-28 female thread.

Product Support and Availability

The 200350-13-00-00 is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and delivery options. We support your industrial automation needs.
