2094-BC01-M01-S | Allen-Bradley Kinetix 6000 Integrated Axis Module - Petro Auto Tech

Product Overview

The 2094-BC01-M01-S is a 400 Volt class Integrated Axis Module from the Kinetix 6000 Motion control system by Allen-Bradley, a brand of Rockwell Automation. This multi-axis servo drive integrates both inverter and converter sections in a single unit. It delivers reliable performance for demanding industrial motion control applications.

Technical Specifications Analysis

The 2094-BC01-M01-S operates on an AC input voltage range of 324 - 528 Vrms, 3-Phase, with nominal voltages of 360 / 480 VAC. It supports a DC input voltage of 458 - 747 VDC for common-bus follower configurations. The module provides a continuous output power to bus of 6 kW and a continuous output current to bus of 9 A. Peak power output reaches 12 kW. Bus overvoltage protection is set at 425V DC, and bus undervoltage at 275V DC. The unit weighs 11.1 pounds and achieves an efficiency of 97%.

Application Scenarios & Usage Methods

This drive excels in multi-axis packaging machines, converting lines, and assembly automation. Use it to control servo motors for precise indexing, cutting, and material handling. The integrated Safe Torque Off (STO) functionality ensures operator safety during maintenance. Connect the module via SERCOS interface using fiber optic media in linear or ring topology for high-speed, noise-immune communication.

Installation Guide & Packing List

Mount the 2094-BC01-M01-S on a power rail inside an enclosure with a minimum depth of 198 mm (7.8 in.). Maintain an installation clearance of 50.8 mm (2.0 in.) around the module for proper airflow. The package includes the Integrated Axis Module and mounting hardware. Refer to the user manual for detailed wiring and configuration steps.

Purchasing Advice

When selecting a servo drive, verify that your application requires a 6 kW converter and 9 A inverter. The 2094-BC01-M01-S is ideal for systems needing integrated safety and high efficiency. Petro Auto Tech offers this genuine Allen-Bradley module with fast shipping and expert support.

Repair & Maintenance Tips

Periodically inspect the module for dust buildup and ensure proper ventilation. Check bus voltage levels to stay within 458 - 747 VDC. Verify STO functionality during routine safety checks. Store the unit in a clean, dry environment when not in use.

Frequently Asked Questions (FAQs)

Q: What is the input voltage range for the 2094-BC01-M01-S?

A: The AC input voltage range is 324 - 528 Vrms, 3-Phase, with nominal voltages of 360 / 480 VAC.

Q: Does this module support Safe Torque Off?

A: Yes, the 2094-BC01-M01-S includes integrated Safe Torque Off (STO) functionality certified to ISO 13849-1 PLe/SIL3.

Q: What is the continuous output power to bus?

A: The module delivers a continuous output power to bus of 6 kW and a continuous output current to bus of 9 A.

Q: How is the module mounted?

A: The 2094-BC01-M01-S mounts on a power rail inside an enclosure with a minimum depth of 198 mm.

Q: What is the weight of this drive?

A: The unit weighs 11.1 pounds.
