2094-BM05-M | Allen-Bradley Kinetix 6200 Multi-Axis Servo Drive - Petro Auto Tech

Product Overview

The Allen-Bradley 2094-BM05-M is a Kinetix 6200 series multi-axis servo drive from Rockwell Automation. This Axis Module provides Integrated Motion capability for motor or drive applications. It features a built-in safe speed monitor device and operates with 460 Volt AC three-phase input power. The drive supports easy transition from Safe Torque Off to Safe Speed Monitor and from SERCOS interface to EtherNet/IP networks. Its modular design simplifies wiring and reduces spare parts inventory.

Technical Specifications Analysis

The 2094-BM05-M delivers an output current of 45 Amperes and a wattage of 22 kWatts. It operates within a nominal drive voltage range of 360-480 Volts (3 Phase) and has a voltage rating of 460 Volt (AC). The ambient operating temperature range is 32-122 F (0-50 C). Dimensions are 5.5 x 11.9 x 14.7 inches (141 x 302 x 426 mm), and it weighs 12.0 lbs (5.44 kg). The drive is an Axis Module with a 45A inverter section and requires one control module with an IAM power module.

Application Scenarios & Usage Methods

This servo drive suits high-performance motion control in packaging, material handling, and assembly lines. Use it with Kinetix 6000 servo drives for easy migration. The embedded Safe Speed Monitor allows maintenance work without stopping the machine, reducing downtime and energy waste. The drive also supports Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control.

Installation Guide & Packing List

Mount the 2094-BM05-M inside a cabinet with adequate ventilation. Ensure the ambient temperature stays within 0 to 50 degrees Celsius. Connect the 3-phase input voltage (360-480 Volts AC) and the control module with an IAM power module. The package typically includes the axis module, mounting hardware, and documentation. Verify all connections before powering up.

Purchasing Advice

When selecting the 2094-BM05-M, confirm your system requires a 460V AC three-phase input and a 45A inverter section. This drive is ideal for applications needing integrated safety features like Safe Speed Monitor. Petro Auto Tech offers genuine Allen-Bradley parts with reliable service. Check compatibility with your existing Kinetix 6000 or 6200 system.

Repair & Maintenance Tips

Regularly inspect the drive for dust buildup and ensure cooling fans operate correctly. Clean the cabinet filters and verify ambient temperature stays within 0-50 C. Check all wiring connections for tightness and signs of wear. Use the enhanced diagnostic features to read error messages for quick troubleshooting. Store spare units in a dry, clean environment.

Frequently Asked Questions (FAQs)

Q: What is the input voltage range for the 2094-BM05-M?

A: The nominal drive voltage is 360-480 Volts (3 Phase) with a voltage rating of 460 Volt AC.

Q: What is the output current of this servo drive?

A: The output current is 45 Amperes.

Q: Does the 2094-BM05-M include safety features?

A: Yes, it has a built-in safe speed monitor device and supports Safe Torque Off, Safe Maximum Speed, Safe Direction Monitoring, and more.

Q: What is the operating temperature range?

A: The ambient operating temperature range is 32-122 F (0-50 C).

Q: Is this drive compatible with Kinetix 6000?

A: Yes, it is compatible with the Kinetix 6000 servo drive for easy migration.
