Product Overview

The 3500/15-05-05-00 is a Bently Nevada 3500/15 AC and DC Power Supply module designed for robust industrial automation systems. This power supply delivers reliable performance with universal AC voltage input, making it a versatile choice for various monitoring and control applications. Manufactured in the U.S.A., the 3500/15-05-05-00 ensures stable operation in demanding environments.

Technical Specifications Analysis

The 3500/15-05-05-00 features a universal AC voltage power supply type (05) that accepts 85 to 264 Vac rms input. It operates with an input frequency of 47 to 63 Hz and provides a maximum input current of 2.8 A rms for universal AC voltage. The module includes a Supply OK LED indicator for easy status monitoring. Physical dimensions are 25.15 cm x 5.08 cm x 12.07 cm (or 120.7 mm x 50.8 mm x 251.5 mm), and it weighs 1.39 kg (3.06 lb). The power supply module occupies two half-height slots on the left side of the rack, allowing for redundant configurations. Environmental limits include an operating temperature range of -30 °C to +65 °C and storage temperature from -40 °C to +85 °C, with humidity tolerance up to 95% non-condensing.

Application Scenarios & Usage Methods

This power supply is ideal for turbine monitoring systems, compressor control panels, and vibration analysis racks in oil and gas, power generation, and heavy industries. Use the 3500/15-05-05-00 to power Bently Nevada 3500 series monitoring modules in critical machinery protection applications. For redundant setups, install two power supply modules in the rack slots to ensure continuous operation. The universal AC input (85 to 264 Vac rms) allows direct connection to standard industrial power sources without additional converters.

Installation Guide & Packing List

Install the power supply module into the designated two half-height slots on the left side of the 3500 rack. Secure the module with the provided screws and connect the power input module (PIM) directly behind the power supply. Ensure the input voltage matches the specified range (85 to 264 Vac rms) and frequency (47 to 63 Hz). The packing list typically includes one 3500/15-05-05-00 power supply module and one power input module (PIM). Additional accessories may vary by supplier.

Purchasing Advice

When selecting a power supply for your 3500 rack, verify the power supply type code (05 for universal AC voltage) and agency approval option (00 for none). The 3500/15-05-05-00 is a reliable choice for standard industrial environments. Petro Auto Tech offers this module with fast shipping and expert support. Confirm compatibility with your existing rack configuration before ordering.

Repair & Maintenance Tips

Regularly inspect the Supply OK LED to confirm proper operation. Keep the module clean and free from dust using a dry cloth. Store the unit within the specified temperature range (-40 °C to +85 °C) and humidity below 95% non-condensing. Avoid exposing the power supply to excessive vibration or corrosive atmospheres. If the LED fails to illuminate, check input power connections and replace the module if necessary.

Frequently Asked Questions (FAQs)

Q: What is the input voltage range for the 3500/15-05-05-00?

A: The universal AC voltage input range is 85 to 264 Vac rms for non-hazardous areas and 85 to 250 Vac rms for hazardous areas.

Q: Can I use two 3500/15-05-05-00 modules for redundancy?

A: Yes, the rack has two half-height slots for power supplies, allowing redundant configurations with two modules.

Q: What does the Supply OK LED indicate?

A: The Supply OK LED illuminates when the power supply is operating properly.

Q: What is the operating temperature range of this power supply?

A: The operating temperature range is -30 °C to +65 °C.

Q: What is the weight of the 3500/15-05-05-00 module?

A: The module weighs 1.39 kg (3.06 lb).
