3500/94M-05-00-CN | Bently Nevada VGA Display Module - Petro Auto Tech

Product Overview

The 3500/94M-05-00-CN is a VGA Display Module from Bently Nevada, designed for industrial monitoring systems. This module provides a clear 15-inch display with 19-inch rack mounting, enabling operators to view machine status, data, and values from the 3500 series monitoring system. It integrates seamlessly with the 3500/22 Transient Data Interface (TDI) module for reliable data presentation.

Technical Specifications Analysis

The 3500/94M-05-00-CN operates with a power consumption of 4.6 watts max. It features an RS232 port for touch controller data and a VGA port for analog red, green, blue, and sync signals. An OK LED indicates proper module operation, while a TX/RX LED shows communications between other system modules. The front port provides 24 Vdc power out, VGA signal out, and touch commands in. Environmental limits include an operating temperature range of -20°C to 65°C (-22°F to 149°F), storage temperature from -40°C to 85°C (-40°F to 185°F), and humidity tolerance of 95% non-condensing. The display module dimensions are 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in) with a weight of 0.73 kg (1.6 lb). The I/O module measures 241.3 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) and weighs 0.34 kg (0.75 lb). The 15-inch Advantech display (FPM-8151) has dimensions of 422 mm x 338 mm x 68 mm (16.61 in x 13.31 in x 2.68 in) and weighs 8.5 kg (18.75 lb). The monitor module requires 1 full-height front slot, and the I/O module needs 1 full-height rear slot. Compliance includes EMC standards EN 61000-6-2 and EN 61000-6-4, electrical safety standards CSA C22.2 61010-1 and UL EN 61010-1, and RoHS Directive 2011/65/EU.

Application Scenarios & Usage Methods

This VGA display module is ideal for continuous monitoring of rotating machinery in power generation, oil and gas, and heavy manufacturing. Operators use the 15-inch display to view real-time vibration data, temperature trends, and alarm status from Bently Nevada monitoring systems. The RS232 port connects a touch controller for intuitive navigation, while the VGA port delivers high-resolution analog signals. The module operates reliably in harsh environments with temperatures from -20°C to 65°C, making it suitable for outdoor or unheated control rooms. Users can mount the display in a 19-inch rack and connect it to the 3500/22 TDI module via the high-speed network for seamless data acquisition.

Installation Guide & Packing List

Install the 3500/94M-05-00-CN in a 19-inch rack using the provided mounting hardware. Secure the monitor module in one full-height front slot and the I/O module in one full-height rear slot. Connect the VGA cable from the I/O module to the display, and attach the power supply (24 Vdc). Ensure the 3500/22 TDI module is installed and configured with firmware Rev 1.71 or newer. The package typically includes the 3500/94M VGA Display Module, I/O module, 15-inch Advantech display, and necessary cables. Verify all components before installation.

Purchasing Advice

When purchasing the 3500/94M-05-00-CN, verify that your system uses the 3500/22 TDI module and compatible firmware versions (3500/94M Firmware 4.06 Rev. C, 3500/22 Firmware Rev 1.71, 3500/01 Rack Config Rev 5.6, 3500/02 Op Display Rev 2.21, 3500/03 Data Acquisition Rev 1.22). This module supports 19-inch rack mounting and a 15-inch display, ensuring easy integration into existing panels. Petro Auto Tech offers genuine Bently Nevada modules with fast shipping and expert support. Choose this model for reliable, high-visibility monitoring in demanding industrial environments.

Repair & Maintenance Tips

Keep the display and module clean using a soft, dry cloth. Avoid exposing the unit to excessive dust or moisture beyond the 95% non-condensing humidity limit. Check the OK LED periodically to confirm proper operation. If the TX/RX LED stops blinking, inspect network connections and the 3500/22 TDI module. Store the module within the -40°C to 85°C storage temperature range when not in use. For any issues, contact a qualified technician familiar with Bently Nevada systems.

Frequently Asked Questions (FAQs)

Q: What is the power consumption of the 3500/94M-05-00-CN?

A: The module consumes 4.6 watts max.

Q: What display size does this module support?

A: It supports a 15-inch display (381 mm diagonal) with 19-inch rack mounting.

Q: What is the operating temperature range?

A: The operating temperature range is -20°C to 65°C (-22°F to 149°F).

Q: Which module is required for the 3500/94M to function?

A: The 3500/94M requires the 3500/22 Transient Data Interface (TDI) module.

Q: What certifications does this module hold?

A: It complies with EMC standards EN 61000-6-2 and EN 61000-6-4, and electrical safety standards CSA C22.2 61010-1 and UL EN 61010-1.
