177230-02-01-CN | Bently Nevada Seismic Transmitter

Introduction to the 177230-02-01-CN

When machinery vibration threatens uptime, the 177230-02-01-CN from Bently Nevada provides a dependable solution. This seismic transmitter converts vibration into a standard 4-20 mA signal, enabling seamless integration with PLCs, DCS, and SCADA systems. Designed for continuous condition monitoring, it helps you detect issues early and avoid costly downtime.

Key Features and Technical Specifications

The 177230-02-01-CN is engineered for accuracy and durability. Its key specifications include:

• Measurement range: 0 to 50.8 mm/s (0 to 2.0 in/s) RMS
• Frequency response: 10 Hz to 1 kHz (600 to 60 kcpm) RMS
• Output: 4-20 mA current loop (Pin A to Pin B)
• Excitation voltage: 12 to 30 Vdc (current limited to 40 mA)
• Operating temperature: -40°C to +85°C (-40°F to +185°F)
• Case material: 316L stainless steel
• Connector: 3-pin MIL-C-5015, 316L stainless steel
• Weight: 0.131 kg (4.62 oz)

These specs ensure reliable performance in harsh industrial environments. The hermetically sealed sensor and 316L stainless steel construction provide excellent corrosion resistance.

Real-World Applications

This seismic transmitter is ideal for monitoring rotating equipment such as pumps, fans, compressors, and motors. Its 4-20 mA output works with most control systems, making it a versatile choice for predictive maintenance programs. For example, in a chemical plant, continuous vibration data helps detect bearing wear before failure, reducing unplanned shutdowns. The transmitter's wide measurement range covers both low and high vibration levels, ensuring accurate monitoring across various machinery types.

Installation and Setup Guidance

Proper installation is crucial for accurate readings. The 177230-02-01-CN features a 1/4-28 UNF mounting hole and M6 x 1 SI, M8 x 1.25 SI, or 1/4-28 UNF mounting threads. Recommended mounting torque is 4 to 7 N-m (35.4 to 62.0 in-lbf). Connect Pin A to the 4-20 mA positive loop and Pin B to the loop return. The dynamic acceleration signal is available on Pin C. Ensure the transmitter is securely mounted to the machine surface for optimal vibration transfer.

Maintenance and Reliability

Routine inspection of the transmitter and its connections helps maintain long-term reliability. The hermetically sealed sensor protects against moisture and contaminants, allowing operation in up to 100% relative humidity (non-submerged). With no moving parts, the ceramic shear sensing element offers excellent stability. Periodic verification of the output signal against a known vibration source ensures accuracy. This low-maintenance design reduces total cost of ownership.

Compatibility and Integration

The 4-20 mA output is universally accepted by PLCs, DCS, and SCADA systems. It is designed for systems with internal power supplies typically current-limited to 30-35 mA. The transmitter operates with an excitation voltage of 12 to 30 Vdc, making it compatible with most industrial power sources. The dynamic acceleration signal on Pin C provides additional diagnostic capability when connected to a suitable data acquisition system.

Common Questions and Troubleshooting

Q: What is the settling time of the 177230-02-01-CN?

A: The settling time is less than 15 seconds within 2% of the final value, ensuring quick response after power-up.

Q: Can the 177230-02-01-CN be used in high-humidity environments?

A: Yes, it operates in up to 100% relative humidity as long as it is not submerged.

Q: What is the transverse sensitivity of this transmitter?

A: Transverse sensitivity is less than 5% of the axial sensitivity, minimizing errors from cross-axis vibration.

Q: How do I verify the output signal?

A: At zero vibration, the output should be 4 ± 0.3 mA; at full scale (25.4 mm/s), it should be 20 ± 2 mA.

Product Support and Availability

The 177230-02-01-CN is available through Petro Auto Tech, your trusted industrial automation parts supplier. We ensure genuine Bently Nevada products with reliable delivery. Contact our team for current stock and lead times.
