3500/94M 119M6509-03 | Bently Nevada Power Supply Cable for 10" Display - Petro Auto Tech

Product Overview

The 3500/94M 119M6509-03 is a Bently Nevada power supply cable designed for a 10-inch Advantech display. This cable connects the rear of a rackmounted 3500/94M IO module (190214-02) to an industrial 24 VDC power supply. It ensures reliable power delivery and data communication for critical monitoring systems in industrial automation environments.

Technical Specifications Analysis

The 3500/94M 119M6509-03 operates with a maximum power consumption of 4.6 watts. It includes an RS232 port for touch controller data and a VGA port for analog red, green, blue, and sync signals to the display. The front port provides 24 VDC power out, VGA signal out, and touch commands in. An OK LED indicates proper module operation, while a TX/RX LED shows communications between system modules. The cable length is 10 ft (3.05 m). Note that cable assembly 107M3696-01 is also required from the front of the 3500/94M module to the display. The environmental limits include an operating temperature range of -20°C to 65°C (-22°F to 149°F), a storage temperature range of -40°C to 85°C (-40°F to 185°F), and humidity tolerance of 95% non-condensing.

Application Scenarios & Usage Methods

This cable is ideal for connecting a Bently Nevada 3500/94M IO module to a display in turbine monitoring systems, compressor control panels, or vibration analysis workstations. Use it to transmit power and video signals from a rackmounted module to a remote display in control rooms. The 10 ft length provides flexibility for mounting the display away from the rack. Ensure the industrial 24 VDC power supply meets the module's requirements for stable operation.

Installation Guide & Packing List

Installation requires connecting one end of the 3500/94M 119M6509-03 to the rear of the 3500/94M IO module and the other end to the 24 VDC power supply. Additionally, connect cable assembly 107M3696-01 from the front of the module to the display. Secure all connections and verify the OK LED illuminates to confirm proper operation. The package includes one Bently Nevada 3500/94M 119M6509-03 power supply cable, new and original in factory packing.

Purchasing Advice

When purchasing the 3500/94M 119M6509-03, verify compatibility with your 3500/94M IO module (190214-02) and industrial 24 VDC power supply. Ensure you also order cable assembly 107M3696-01 if not already available. Petro Auto Tech offers this product with a 12-month factory warranty and original packaging for reliable performance.

Repair & Maintenance Tips

Regularly inspect the cable for wear, cuts, or loose connections. Keep the cable away from sharp edges and excessive heat sources. Store the cable in a clean, dry environment within the specified storage temperature range of -40°C to 85°C. Avoid bending the cable sharply to prevent internal wire damage. Clean connectors with a dry cloth to maintain signal integrity.

Frequently Asked Questions (FAQs)

Q: What is the length of the 3500/94M 119M6509-03 cable?

A: The cable is 10 ft (3.05 m) long.

Q: What power supply voltage does this cable support?

A: It connects to an industrial 24 VDC power supply.

Q: What is the maximum power consumption of the module when using this cable?

A: The maximum power consumption is 4.6 watts.

Q: What additional cable is required for full installation?

A: Cable assembly 107M3696-01 is also required from the front of the 3500/94M module to the display.

Q: What are the operating temperature limits for this cable assembly?

A: The operating temperature range is -20°C to 65°C (-22°F to 149°F).
