Output Module 3636T 32-Point Non-Triplicated 155 VAC/VDC

Product Overview

The 3636T is a robust output module. It provides 32 non-commoned points. This module is non-triplicated for simpler designs. It supports a maximum voltage range of 155 VAC/VDC. Each point can handle a current load of 2A. The switching power is 2000 VA resistive. The maximum wattage is 150 watts. It uses normally open contacts. The color code is silver blue. This module offers reliable performance for demanding tasks.

Application Scenarios

Use the 3636T in industrial control systems. It works well for discrete output control. It is ideal for switching resistive loads. Use it in automation and manufacturing lines. It fits into machinery monitoring setups. The module works with PLC and PAC systems. It is suitable for power and electrical components. It can control actuators and indicators. The high point isolation ensures signal integrity.

Technical Specifications

The module has 32 points. They are non-commoned for flexibility. The voltage range is 155 VAC/VDC maximum. The current load is 2A maximum per point. Switching power is 2000 VA resistive. Maximum wattage is 150 watts. Point isolation is 1500 VDC. For the 3636T model, isolation is 2500 VDC. Each output has a 2.5A fast-acting fuse. Diagnostic indicators show output status. They also show module status. You can see PASS, FAULT, and ACTIVE signals. The output contact is normally open. The color code is silver blue.

Installation & Maintenance Guide

Mount the module securely in a chassis. Ensure proper ventilation for cooling. Connect wiring to the normally open contacts. Use the correct wire gauge for 2A loads. Check the 2.5A fuse per output regularly. Replace fuses with the same type only. Monitor the diagnostic indicators. The ACTIVE light shows output operation. The FAULT light signals a problem. Keep the module clean and dry. Do not exceed the 155 VAC/VDC limit. Follow all safety procedures during work.

Packing List

1 x 3636T Output Module. Shipping is via Fedex, UPS, or DHL.
