Allen-Bradley 1734-4IOL IO-Link Master Module

Product Overview

The Allen-Bradley 1734-4IOL is a highly functional IO-Link Master Module. It integrates seamlessly into the Point I/O series. This module offers four distinct channels. You can connect various sensors and actuators for automation scenarios. It uses a 5V DC backplane power supply. The module consumes 100 mA. Input ratings are 24V DC and 12 mA. Output ratings are 24V DC with 0.15 mA per channel. The module handles an input voltage from 13V DC to 30V DC. Output voltage ranges from 19.2V DC to 28.8V DC. It operates between -20 and 55 degrees Celsius. Storage temperature ranges from -40 to 85 degrees Celsius. This 1734-4IOL module is ideal for industrial environments. Its reliability and adaptability to temperature changes are key features.

Application Scenarios

You can use the 1734-4IOL in factory automation, material handling, and process control systems. It works well with smart sensors and actuators. The module simplifies wiring and reduces downtime. It supports IO-Link communication for data exchange. Applications include conveyor systems, packaging machines, and assembly lines. It fits in distributed control cabinets and panel-mounted setups.

Technical Specifications

• Power Supply: backplane 5V DC, 100 mA
• Input: 24V DC, 12 mA
• Output: 24V DC, 0.15 mA per channel
• Input voltage range: 13V DC to 30V DC
• Output voltage range: 19.2V DC to 28.8V DC
• Operating temperature: -20 to 55°C
• Storage temperature: -40 to 85°C
• Number of channels: 4
• Series: Point I/O

Installation & Maintenance Guide

Install the module on a standard Point I/O backplane. Ensure power is off before connecting. Mount the module securely. Use appropriate connectors for sensors and actuators. Follow the wiring diagram from the user manual. Test each channel after installation. For maintenance, check for loose connections regularly. Keep the module clean and dry. Replace only with authorized parts. The 1734-4IOL requires no special tools for installation.
