Flexem FC5M-20MN-AC PLC Controller with 12 Inputs & 8 Outputs

Product Overview

The Flexem FC5M-20MN-AC is a programmable logic controller built for small to medium automation tasks. This unit features 12 digital inputs and 8 transistor outputs. It operates on a 220V AC power supply. The controller includes a built-in Ethernet port for easy network integration. It also supports high-speed pulse inputs and outputs for precise motion control.

Application Scenarios

This PLC works well in packaging machines, conveyor systems, and simple assembly lines. It can also control lighting systems or small HVAC units. The high-speed inputs and outputs make it a good fit for labeling machines or pick-and-place devices. Use it in any environment that needs reliable logic control.

Technical Specifications

The device has 12 input points. Seven of these are high-speed inputs that run at 100 KHz. The 8 output points are NPN transistors. Six outputs support high-speed pulse trains up to 200 KHz. The power supply accepts 220V AC. The unit also has one RS485 port and one RS485/RS232 port. A USB Type-C port allows for program upload and download. The controller includes a real-time clock and a detachable terminal block for wiring.

Installation & Maintenance Guide

Mount the controller on a DIN rail inside a control cabinet. Use shielded cables for high-speed signals. Keep cable length under 5 meters for fast inputs and outputs. For standard I/O, use cables up to 100 meters. Ensure the ambient temperature stays between -10°C and 60°C. Regularly check the terminal block connections to prevent loose wires.

Packing List

The package includes one Flexem FC5M-20MN-AC PLC controller. It comes with one detachable terminal block. A quick start guide is also included. No power cord or programming cable is provided.
