GE IS215VCMIH2C VME Bus Master Controller Board Mark VI

Product Overview

The GE IS215VCMIH2C is a VME Bus Master Controller Board. It belongs to the Mark VI series. This board uses a 32-bit processor. It has dual-port memory for fast data access. The board handles 12 channels. It provides analog output current from 0 to 20 mA. The frame rate is 10 ms. This ensures reliable and timely communication.

This board is a 6U form factor. It measures 10.16 cm wide by 33.02 cm. The board requires +5 V dc power. It operates in temperatures from -30 to +65 C. The board includes indicator LEDs for Run, Fail, Status, and Reset. The functional abbreviation is VCMI. The instruction manual is GEH-6421.

Application Scenarios

This controller board works in turbine control systems. It is ideal for Mark VI distributed control systems. It manages VME bus communication. It is a master controller for I/O modules. It is suitable for industrial automation. It is used in power generation plants. It also works in oil and gas facilities. The board handles critical control tasks.

Technical Specifications

The board type is 6U. The processor is 32-bit. The memory is dual-port. The frame rate is 10 ms. The analog output current is 0-20 mA. The power requirement is +5 V dc. The operating temperature range is -30 to +65 C. The size is 17.8 cm wide x 33.02 cm. The shipping weight is 1 lb. The country of origin is the United States. The system version is 3. It supports network version for TMR systems.

Installation & Maintenance Guide

Install the board in a VME backplane. Ensure the power is off. Align the board with the slot. Push it firmly into place. Secure it with screws. Connect the cables. Power on the system. Check the LEDs for proper status. The Run LED should be on. The Fail LED should be off. For maintenance, clean the board with dry air. Check connections regularly. Replace if any damage is visible.

Packing List

The package includes one GE IS215VCMIH2C board. It also includes the instruction manual. No extra cables are included. The board is packed in an anti-static bag. It is shipped in a sturdy box. We ship via Fedex, UPS, or DHL.
