Product Summary
The 1734-IB8SK is a conformally coated safety input module for GuardLogix systems. It monitors eight safety devices like e-stops and light curtains. This module supports SIL 3 applications and provides reliable signal processing in corrosive atmospheres.
Why Procurement Experts Choose the 1734-IB8SK
This module solves critical safety distribution needs for system architects. The 1734-IB8SK integrates seamlessly with GuardLogix and Compact GuardLogix controllers. Its conformal coating protects against moisture and chemical exposure. This feature extends the module's lifespan in demanding industrial zones. The unit offers SIL 3 and Category 4 compliance. This certification ensures your machinery meets strict international safety standards. Procurement managers value the reduction in wiring complexity. The module's sinking input configuration simplifies connection to standard safety devices.
Installation Guide for the 1734-IB8SK Module
Start by mounting the module on a standard 8-Point Terminal Base. Ensure the backplane provides power from an adapter or expansion supply. You do not require a separate field bus power supply for operation. Wire your safety devices to the 8 sinking input channels. Each channel accepts an input voltage range of 18 to 30 VDC. The minimum on-state current is 3.3 mA for reliable detection. Configure the four Pulse Test outputs for T0, T1M, T2, or T3M sources. These outputs supply up to 0.7 A per channel. The total output current reaches 2.8 A at 40 degrees Celsius. Use the pulse test feature to verify sensor and wiring integrity. Set the individual on and off delays to match your application needs. This module supports both single and dual channel operation modes. Its input reaction time is under 16.2 ms for fast response.
