Allen-Bradley 1746-HSCE High-Speed Counter Module for SLC 500

Product Summary

The 1746-HSCE is a high-speed counter module designed for the SLC 500 platform. It processes bidirectional counting and motion detection tasks with precision. This module accepts both differential and single-ended inputs at 5VDC. Its maximum input frequency of 50 kHz suits demanding applications. The module features four open-collector outputs for direct control.

Theme Selection: Product Procurement & Buyer Guide

You need a reliable high-speed counter module for your SLC 500 chassis. The 1746-HSCE delivers robust performance for counting and motion control. It occupies a single slot in any local or remote chassis. This module draws 320 mA from the 5V backplane supply. Ensure your power supply can handle this current load.

The module requires a 1746-RT25G I/O connection cable for wiring. Use Belden 9503 cable or an equivalent for signal integrity. This cable can extend up to 305 meters from the module. The A, B, and Z inputs accept 5VDC differential or 0-5VDC single-ended signals. The minimum pulse width is 10 µs with a separation of 4.5 µs.

Choose the operating mode that fits your application. The Sequencer mode handles a maximum frequency of 50 kHz. The Range and Rate modes support up to 32.767 kHz. The module also includes a limit switch input for additional control. This input works with 5VDC, 12VDC, or 24VDC nominal voltages.

The four open-collector outputs provide direct actuator control. Set Switch 2 on for outputs operating at 4.5 to 10VDC. Set Switch 2 off for outputs operating at 10 to 30VDC. The on-state current reaches 125 mA at 30VDC. This allows direct connection to many industrial loads.

The module operates reliably in temperatures from 0°C to +60°C. It can survive storage temperatures from -40°C to +85°C. The module tolerates relative humidity from 5% to 95% without condensation. You must install it inside a NEMA-rated enclosure for protection. The isolation voltage is 1500 volts for robust electrical safety.

Theme Selection: Maintenance, Troubleshooting & Longevity Protocols

Regular maintenance ensures your module operates at peak performance. Inspect the diagnostic LEDs on the front panel frequently. These LEDs indicate CPU faults, fault codes, and error codes. The module also provides an internal status word in the input data file. Monitor this status word for detailed operational information.

Check all wiring connections for signs of corrosion or damage. Verify that the Belden 9503 cable remains securely connected. Ensure the cable length does not exceed 305 meters. Test the input signals with an oscilloscope to confirm pulse integrity. The minimum pulse width must stay above 10 µs.

Keep the module and enclosure clean from dust and debris. Use dry compressed air to clean the module periodically. Verify that the ambient temperature stays within the 0°C to +60°C range. Monitor the backplane current draw to ensure it stays at 320 mA. A deviation may indicate a developing fault.

Test the open-collector outputs under load conditions regularly. Measure the on-state voltage drop across each output. Confirm that the output current stays within the specified limits. Verify that Switch 2 is set correctly for your output voltage range. Replace the module if you detect any erratic output behavior.

Update the module’s configuration when changing application requirements. Review the operating mode settings for Sequencer, Range, or Rate modes. Adjust the input frequency parameters to match your encoder or sensor. Test the step response time of 100 milliseconds for inputs. The output response time is 2.5 milliseconds for fast reaction.
