Introduction
Petro Auto Tech is pleased to offer the Allen-Bradley 2094-BC07-M05-M, a Kinetix 6000 Integrated Axis Module. This converter module delivers robust power conversion for demanding industrial motion control applications. It combines high power density with advanced safety features to improve system reliability and operator protection.
Key Features
The 2094-BC07-M05-M features a converter section output of 45 kW and an inverter section output of 49 A. These ratings enable the module to drive multiple servo axes efficiently. The module accepts a nominal drive voltage of 360-480 Volts, 3-phase, making it suitable for global installations. Its integrated design simplifies wiring and reduces spare parts inventory. Built-in safety features like Safe Speed and Safe Maximum Acceleration Monitoring help protect personnel and equipment.
Technical Specifications
The module operates within a temperature range of 32-122 F (0-50 C), ensuring reliable performance in typical industrial environments. Its dimensions are 7.7 x 11.9 x 16.7 inches (196 x 302 x 426 mm), and it weighs 22.0 lbs (9.98 kg). The continuous output current to the bus is 67.7 A, supporting high-demand applications. The maximum bus capacitance of 17,915 microfarads provides stable DC bus voltage for consistent motor control.
Applications
This integrated axis module excels in packaging machinery, material handling systems, and assembly lines. In packaging, it provides precise speed and torque control for conveyors and fillers. For material handling, it powers lifts and sorters with high dynamic response. In assembly applications, it coordinates multiple axes for accurate part placement and fast cycle times.
Availability
Petro Auto Tech maintains the 2094-BC07-M05-M in stock and ready to ship. Our inventory ensures short lead times for urgent projects. Contact Petro Auto Tech for pricing and availability. Our team provides technical support to help with integration and configuration.
Frequently Asked Questions
What is the lead time for the 2094-BC07-M05-M?
Petro Auto Tech stocks the 2094-BC07-M05-M for immediate shipment. Typical lead time is 1-3 business days depending on order volume and shipping location. Contact our sales team for expedited options.
Does the 2094-BC07-M05-M come with a warranty?
Yes, Petro Auto Tech provides a standard warranty on all Allen-Bradley products. The warranty covers defects in materials and workmanship. Contact our support team for specific terms and claim procedures.
What are the compatible systems for the 2094-BC07-M05-M?
The 2094-BC07-M05-M is part of the Kinetix 6000 series and integrates with Allen-Bradley ControlLogix and CompactLogix controllers. It uses SERCOS interface for high-speed communication. The module requires a control input fuse of FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) and a control input breaker of 1492-SPM2D060 or 1492-SPM1D150.
