Introduction
Petro Auto Tech is pleased to offer the Allen-Bradley 2094-BM01-S Kinetix 6000 Axis Module. This integrated axis module belongs to the Kinetix 6000 multi-axis drive family. It serves as a core component for precise motion control in industrial automation. The module provides direct connection to controlled devices via feedback cables. It mounts on a power rail alongside other Kinetix modules. This design enables synchronized control of multiple motors in complex machinery. The 2094-BM01-S enhances productivity and safety in manufacturing environments.
Key Features
The 2094-BM01-S delivers a continuous output current of 6.1 A and a peak current of 8.6 A. It provides a continuous power output of 3.9 kW. These specifications support demanding motion applications that require rapid acceleration and deceleration. The module achieves 98% efficiency, reducing energy waste and heat generation. It includes Safe Torque Off functionality, which prevents unexpected motor restarts. This safety feature increases machine uptime and operator protection. The integrated shunt handles continuous power of 50 W and peak power of 5.6 kW. This shunt dissipates excess regenerative energy, protecting the drive system.
Technical Specifications
The 2094-BM01-S operates with a nominal input voltage of 650 Volts DC. It belongs to the 400V voltage class and accepts a nominal drive voltage of 360-480 Volts (3 Phase). This voltage range suits common industrial power systems worldwide. The module dissipates 57-126 Watts of power, depending on load conditions. Proper ventilation ensures reliable operation within this range. The velocity loop bandwidth reaches 500 Hertz, while the current loop bandwidth reaches 1300 Hertz. These high bandwidths enable fast and accurate motor control. The internal shunt resistor has a resistance of 115 Ohms. This value determines the shunt's ability to absorb regenerative energy.
Applications
The 2094-BM01-S excels in packaging machinery. It controls servo motors that manage film tension, cut length, and seal timing. The module also suits material handling systems. It synchronizes conveyor belts and robotic pick-and-place units. Assembly lines benefit from its precise position control. The module coordinates multiple axes for tasks like screw driving and part insertion. Its Safe Torque Off feature allows operators to safely access machinery during setup. The peak enhancement configuration handles applications needing short bursts of high torque. This reduces the number of axis modules required, saving panel space.
Availability
Petro Auto Tech maintains stock of the Allen-Bradley 2094-BM01-S for immediate shipment. Our inventory ensures short lead times for urgent projects. We offer competitive pricing and flexible shipping options. Contact Petro Auto Tech for pricing and availability. Our team provides technical support to help with integration and configuration. We understand the importance of minimizing downtime in industrial operations. Choose Petro Auto Tech for reliable supply chain support.
Frequently Asked Questions
What is the lead time for the 2094-BM01-S?
Petro Auto Tech typically ships the 2094-BM01-S within 24-48 hours of order confirmation. Our large inventory reduces lead times compared to direct manufacturer orders. We also offer expedited shipping for emergency requirements. Contact our sales team for current stock status and delivery estimates.
Does the 2094-BM01-S come with a warranty?
Yes, Petro Auto Tech provides a standard warranty on all Allen-Bradley products. The 2094-BM01-S includes a manufacturer-backed warranty against defects in materials and workmanship. We also offer extended warranty options for additional coverage. Our support team assists with warranty claims and replacement processes.
What are the compatible systems for the 2094-BM01-S?
The 2094-BM01-S integrates with Kinetix 6000 multi-axis drive systems. It mounts on a shared power rail with other Kinetix modules. The module works with compatible Allen-Bradley servo motors and feedback devices. It requires a 650V DC input from the drive's DC bus. The module supports Safe Torque Off when paired with an external safety relay meeting EN954-1 Category 3 standards. For specific system compatibility, consult the product manual or contact Petro Auto Tech.
