Introducing the 1746-OB16: A High-Current DC Output Solution
The Allen-Bradley 1746-OB16 is a digital DC output module from the SLC500 series, manufactured by Rockwell Automation. It features sixteen (16) output channels in a single group, delivering a 24VDC output signal. This module is designed for applications requiring high current, with a continuous current per point of 1.5 A at 30 °C and 1.0 A at 55 °C, and a maximum continuous current per module of 6.4 A across 0 to 60 °C.
Technical Specifications Analysis: Key Parameters for Cost Efficiency
The 1746-OB16 operates with an output voltage range of 10-30VDC and a source voltage range of 10-50 Volts DC, ensuring flexibility in various control systems. Its fast switching performance is evident from the output delay times: 1.0 ms from OFF to ON and 0.1 ms from ON to OFF, which reduces cycle times and improves machine throughput. The module dissipates 7.6 Watts of heat, a factor that influences enclosure cooling costs and long-term energy expenses.
Application Scenarios and Use Cases for the 1746-OB16
In packaging lines, the 1746-OB16 can drive solenoid valves and actuators with its 16 high-current outputs, reducing the need for additional interposing relays. For material handling systems, the module's 1.5 A per point capability allows direct control of motor starters, simplifying wiring and lowering installation costs. Its 0.1 ms OFF delay also supports precise timing in high-speed sorting applications.
Customer Case Scenario: Reducing Downtime in a Bottling Plant
Consider a bottling facility that replaced aging relay panels with the 1746-OB16 module. By consolidating 16 outputs into a single module, the plant reduced wiring complexity and cut troubleshooting time by 30%. The fast switching response minimized product jams, directly improving line efficiency and reducing waste.
Compatibility and Integration with SLC500 Systems
The 1746-OB16 integrates seamlessly into Allen-Bradley SLC500 chassis, communicating via the backplane with a current draw of 0.135 A at 5.1 Volts. This low backplane consumption allows more modules per rack, maximizing I/O density and reducing per-point costs. The module is compatible with SLC 5/01, 5/02, 5/03, 5/04, and 5/05 processors, making it a versatile choice for system upgrades.
Frequently Asked Questions About the 1746-OB16
What is the maximum continuous current per module for the 1746-OB16?
The maximum continuous current per module is 6.4 A at 0 to 60 °C (32 to 140 °F), as specified in the technical data. This rating ensures reliable operation under full load without exceeding thermal limits.
What is the OFF-state leakage current of the 1746-OB16?
The OFF-state leakage current is 1 mA, which helps prevent false activation of connected loads. This low leakage is critical in sensitive applications to avoid unintended machine motion.
Can the 1746-OB16 be used in high-temperature environments?
Yes, the module is rated for continuous operation up to 60 °C (140 °F). However, the continuous current per point derates from 1.5 A at 30 °C to 1.0 A at 55 °C, so thermal management should be considered for maximum output.
