Allen-Bradley 22F-D024N114 PowerFlex 4M AC Drive, 15 HP

June 23, 2026 • 3 min read • wayne • Science

Product Summary

The 22F-D024N114 is a compact AC drive from the PowerFlex 4M series. This unit delivers reliable open-loop speed control for three-phase motors. It provides 24 Amps of output current at 480 Volts AC. The drive comes with a built-in EMC filter and an IP20 enclosure.

Expert Technical Evaluation & Performance Review

This drive offers robust performance for industrial applications. The 22F-D024N114 operates on a 380-480V AC three-phase input supply. It produces a variable output of 0-460V AC for precise motor control. The drive supports motors up to 15 Horsepower or 11 Kilowatts.

The unit uses a standard V/Hz control algorithm for reliable speed regulation. Its built-in speed potentiometer allows for quick manual adjustments. The 4-digit display and LED indicators provide clear operational status. An internal IGBT brake dynamic braking resistor supports rapid deceleration.

Environmental tolerances are critical for longevity. This drive functions in ambient temperatures from -10 to 40 degrees Celsius. It can withstand non-operating temperatures down to -40 degrees Celsius. The unit operates reliably at altitudes up to 1000 meters without derating. Non-condensing humidity levels can range from 0 to 95 percent.

The 22F-D024N114 features a robust mechanical design. It can handle operating vibration of 1 g peak from 5 to 2000 Hz. The drive also survives operating shock of 15 g peak for 11 milliseconds. Install this unit in a clean area free from dust or corrosive gas.

Deep-Dive Technical FAQ

Question 1: What communication protocol does this drive support?

This drive integrates an RS-485 communication port for network connectivity. You can use this port for basic serial control and monitoring.

Question 2: What are the exact input current and kVA ratings?

The input ratings for this drive are 26.1 Amps and 21.7 kVA. The input voltage range is 340 to 528 Volts AC.

Question 3: What type of I/O is available on this drive?

The drive includes one analog PTC input and one unipolar voltage input. It also has five 24V DC digital inputs with two programmable options. A single Form C relay output is present for status signaling.

Question 4: What is the correct enclosure type for this model?

The 22F-D024N114 comes with an Open Type enclosure rated IP20. This rating protects against solid objects larger than 12.5 mm. It does not protect against water ingress.

Question 5: Can this drive be used for closed-loop control applications?

This specific model is suitable for open-loop speed regulation only. It uses a Volts per Hertz motor control method. You should not use this drive for applications requiring encoder feedback.
