Product Summary
The 22F-RF6P0-AS is an EMC line filter kit for PowerFlex 4M drives. This S-type filter handles 3-phase power at 200-240V AC. It supports a maximum current of 6.0A for short cable runs. This module ensures compliance with strict electromagnetic interference standards.
Theme A: Product Procurement & Buyer Guide
This filter kit solves critical EMC compliance issues for control panels. The 22F-RF6P0-AS specifically reduces electrical noise from drive cables. Procurement teams must match this filter to a 200-240V AC system. This model works exclusively with short motor cable lengths. It supports PowerFlex 4M drives rated from 0.4 to 1.5 kW. Engineers should verify the input voltage before ordering this part. This kit prevents costly downtime caused by electrical interference. It also protects sensitive nearby equipment from signal distortion. The filter integrates directly with the drive mounting system. This design simplifies the overall assembly process for technicians.
Theme A: Application Engineering Insights
Application engineers must align this filter with the drive's power stage. The 22F-RF6P0-AS operates at a standard frequency of 50/60 Hz. This ensures compatibility with global industrial power grids. The S-type designation defines its attenuation for short cables. This filter does not support long cable installations above a certain length. For long cable runs, consider the L-type filter variant. The kit includes all necessary hardware for a secure connection. Its compact form factor fits within tight enclosure spaces. This feature is vital for retrofitting into existing machine cabinets. The module improves overall system reliability by suppressing conducted emissions.
Logistics & Standard Packaging Details
- One EMC filter module for PowerFlex 4M drives
- Mounting hardware kit for panel installation
- Installation guide with wiring diagrams
- Shipping: Express delivery via FedEx, UPS, and DHL.
