Product Summary
The IS215VCMIH2C is a critical VME Bus Master Controller from General Electric. It serves as the central communication hub within the Mark VI Speedtronic Control System. This board links the main processor to all I/O modules and the IONet network. It manages board IDs and acts as the VME bus master. This component is essential for reliable turbine control operations.
Theme A: Product Procurement & Buyer Guide for the IS215VCMIH2C
Procurement managers must recognize the IS215VCMIH2C as a critical spare part. This board prevents costly downtime in gas and steam turbine systems. It is a "C" revision of the original IS215VCMIH2 model. This revision indicates functional performance changes without altering the physical design. You must verify compatibility with your existing Mark VI rack.
This VME Bus Master Controller requires a +5 V dc power supply. It operates reliably in extreme temperatures from -30 to +65 °C. The board dimensions are 10.16 cm wide by 33.02 cm deep. It uses a 32-bit processor and dual-port memory for fast data handling. The frame rate operates at a swift 10 ms for real-time control.
The board features three IONet 10Base2 Ethernet ports for network redundancy. These ports support the R, S, and T channels for triple modular redundancy. It also includes one RS-232C serial port for local diagnostics. Front panel LEDs indicate Run, Fail, Status, and Reset conditions. This allows for quick visual status checks during operation.
You should confirm the system software version before installation. This board works with System Version 3 and specific TMR network versions. The official instruction manual is GEH-6421M. Always source this part with its full functional number for accuracy. The country of origin for this unit is the United States.
This component weighs only 1 lb, making it easy to handle. It is a 6U form factor board designed for standard VME racks. The board manages up to 12 channels of communication. It provides an analog output current range of 0-20 mA. These specifications ensure it meets demanding industrial automation needs.
Logistics & Standard Packaging Details
- One GE IS215VCMIH2C VME Bus Master Controller Board
- Anti-static packaging for safe transit and storage
- Product documentation referencing manual GEH-6421M
- Express delivery shipping is available via FedEx, UPS, and DHL
- Standard repair service turnaround of 3-7 days
