106M6694-01 Bently Nevada DIN Rail Power Supply — 24V DC Output

What Makes the Bently Nevada 106M6694-01 Power Supply Essential for Your System?

When your monitoring system demands a stable and reliable power source, the 106M6694-01 from Bently Nevada delivers exactly that. This DIN rail-mounted power supply converts 110/220 VAC input to a regulated 24 VDC output at 5 A, capable of driving up to 10 monitors. Designed for industrial environments, it operates across a wide temperature range from -40°C to 70°C, ensuring consistent performance even in harsh conditions.

Key Features and Technical Specifications of the 106M6694-01

• Input Voltage: 110/220 VAC, making it suitable for global applications.
• Output: 24 VDC at 5 A, providing ample power for multiple devices.
• Mounting: DIN rail compatible for easy installation in control cabinets.
• Temperature Range: -40°C to 70°C, ensuring reliable operation in extreme environments.
• Dimensions: 40 x 130 x 12 mm, compact footprint saves panel space.
• Drive Capacity: One power supply can drive up to 10 monitors, simplifying system design.
• Certifications: UL listed for Class I, Division 2 hazardous locations, plus ATEX and IECEx approvals.

Installation and Setup Guide for the 106M6694-01

Mount the 106M6694-01 securely on a standard DIN rail within your control panel. Ensure the input voltage matches your facility's supply (110 or 220 VAC). Connect the output terminals to your monitoring equipment, respecting polarity. The compact dimensions (40 x 130 x 12 mm) allow for dense packing. Always follow local electrical codes and the manufacturer's manual for safe wiring.

Maintenance and Reliability Tips

Regularly inspect the power supply for dust buildup and ensure adequate ventilation around the DIN rail mount. The wide temperature tolerance (-40°C to 70°C) reduces thermal stress, extending service life. Periodically verify output voltage with a multimeter to confirm 24 VDC regulation. For critical systems, consider redundant power supplies to maximize uptime.

Frequently Asked Questions about the 106M6694-01

What is the input voltage range of the 106M6694-01?

The input voltage is 110/220 VAC, as specified in the product data.

How many monitors can one 106M6694-01 power supply drive?

One power supply can drive up to 10 monitors, according to the specifications.

What certifications does the 106M6694-01 hold?

It is certified for Class I, Division 2 by UL, and also carries ATEX and IECEx approvals.

What are the dimensions of the 106M6694-01?

The dimensions are 40 x 130 x 12 mm, making it compact for DIN rail mounting.

What is the operating temperature range?

The operating temperature range is -40°C to 70°C.

Product Support and Availability

The 106M6694-01 is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and lead times. We are your trusted supplier for Bently Nevada industrial automation parts.
