170MCI10001 | Schneider 1m Interbus Cable for Modicon Quantum

Introduction to the 170MCI10001

When you need a dependable connection for your Modicon Quantum automation network, the 170MCI10001 from Schneider Electric delivers the performance you expect. This 1-meter cable supports the Interbus protocol, ensuring efficient data exchange between devices. Its compact design and black color make it a practical choice for industrial environments.

As part of the Modicon Quantum series, this cable is engineered to meet the demands of modern manufacturing. Whether you are upgrading an existing system or building a new one, the 170MCI10001 provides the reliability you need.

Key Features and Technical Specifications

• Manufacturer: Schneider Electric
• Product Type: Cable
• Product Line: Modicon Quantum
• Part Number: 170MCI10001
• EAN: 3595860027139
• Weight: 0.19 lbs (0.09 kg)
• Protocol: Interbus
• Length: 1 meter
• Color: Black
• Operating Temperature: 0 to 40 degrees Celsius
• Storage Temperature: 0 to 50 degrees Celsius
• Maximum Operating Humidity: 80% RH without condensation
• Maximum Storage Humidity: 80% RH without condensation
• Maximum Operating Altitude: 1000 meters above sea level without derating
• Environment: Indoor environment with no corrosive chemicals

The 170MCI10001 is designed for indoor use, where it can operate reliably within the specified temperature and humidity ranges. Its lightweight construction makes installation straightforward, even in tight spaces.

Applications and Use Cases

In industrial automation, communication cables are the lifeline of the system. The 170MCI10001 is ideal for connecting programmable logic controllers (PLCs) and other devices that use the Interbus protocol. It is commonly used in manufacturing lines, material handling systems, and process control applications.

For example, in a packaging plant, the 170MCI10001 can link sensors and actuators to the central controller, ensuring real-time data flow. Its 1-meter length is perfect for short-distance connections within control cabinets or between adjacent machines.

Installation and Setup

Installing the 170MCI10001 is simple. First, verify that the cable length is sufficient for your application. Then, connect the cable to the appropriate Interbus ports on your devices. Ensure that the connectors are securely fastened to prevent signal loss.

Because the cable is designed for indoor environments, avoid exposing it to corrosive chemicals or extreme temperatures. Follow standard wiring practices to maintain signal integrity.

Maintenance and Reliability

To ensure long-term reliability, inspect the 170MCI10001 periodically for signs of wear or damage. Check the connectors for corrosion or loose connections. The cable's operating temperature range of 0 to 40 degrees Celsius means it should not be used in excessively hot or cold environments.

With proper care, this cable can provide years of trouble-free service, reducing downtime and maintenance costs.

Compatibility and Integration

The 170MCI10001 is specifically designed for the Modicon Quantum series from Schneider Electric. It supports the Interbus protocol, which is widely used in industrial networks. This cable is compatible with other Interbus-enabled devices, allowing for flexible system integration.

Before purchasing, verify that your equipment supports Interbus to ensure seamless communication.

Troubleshooting and Common Issues

If you experience communication errors, first check the cable connections. Ensure that the cable is not damaged and that the connectors are clean. Also, verify that the cable length does not exceed the maximum allowed for your network topology.

If problems persist, consult the Schneider Electric documentation or contact Petro Auto Tech for technical support.

FAQ

What is the length of the 170MCI10001?

The 170MCI10001 is 1 meter long.

What protocol does the 170MCI10001 support?

The 170MCI10001 supports the Interbus protocol.

What is the operating temperature range for the 170MCI10001?

The operating temperature range is 0 to 40 degrees Celsius.

Can the 170MCI10001 be used outdoors?

No, it is designed for indoor environments without corrosive chemicals.

What is the weight of the 170MCI10001?

The cable weighs 0.19 lbs (0.09 kg).

Product Support and Availability

The 170MCI10001 is available from Petro Auto Tech. We stock this cable and can ship it quickly to minimize your downtime. Contact our team for pricing and availability.
