1756-M14 Allen-Bradley ControlLogix Memory Module 3.5 MB

Product Overview

The Allen-Bradley 1756-M14 is a memory expansion module. It belongs to the ControlLogix family. This module adds 3.5 Megabytes of volatile memory. It is designed for ControlLogix5555 controllers. These controllers support redundancy systems. The module works with nonvolatile memory options. It can use two EEPROM units on the same module. The design is simple and reliable. You do not need special tools for installation. The slot is easy to reach on the controller side.

Application Scenarios

This module suits industrial automation environments. It works best in systems needing extra memory. Use it for complex control logic. It supports data-intensive applications. The module is ideal for redundant control systems. It fits in manufacturing plants and process control. Use it in environments without corrosive materials. The operating temperature range is 0 to 60 degrees Celsius. This ensures stable performance in normal conditions.

Technical Specifications

The 1756-M14 has a 3.5-Megabyte capacity. It is a volatile memory module. The module belongs to the A-Series. It is a spare part for ControlLogix5555 controllers. The recommended storage temperature is -40 to 85 degrees Celsius. The module is designed for long-term reliability. It does not need special equipment for installation. The module supports redundancy systems. It can work with nonvolatile memory for controllers that support two EEPROM units.

Installation & Maintenance Guide

Disconnect all power before installation. This includes the battery module power. This step prevents electrical arcs. Arcs can damage the memory board. The slot is easily accessible on the controller side. Insert the module firmly into the slot. No special tools are required. Keep the module away from corrosive materials. Store the module in a dry place. Follow the recommended storage temperature range. This ensures a long service life.

Packing List

1 x Allen-Bradley 1756-M14 ControlLogix Memory Module. 1 x Installation Guide.
