200151-60-02-10 | Bently Nevada 6.0 Meter Accelerometer Standard Cable

Introduction to the Bently Nevada 200151-60-02-10

When reliable vibration data is critical for machinery protection, the 200151-60-02-10 from Bently Nevada provides a robust connection between accelerometers and monitoring systems. This standard cable is designed for industrial environments where signal integrity and mechanical durability are paramount.

Part of the 200151 series, the 200151-60-02-10 features a 6.0 meter length, blue PVC jacket without armor, and enhanced coupling nuts on both ends. These nuts offer a better grip for tightening the cable to the accelerometer, ensuring a secure fit during operation.

Key Features and Technical Specifications

• Cable length: 6.0 meters (model -60).
• Armor option: 02 = Blue cable without armor.
• Coupling nut: 10 = Enhanced coupling nut for better grip on both ends.
• Minimum bend radius: 63.5 mm (2.5 in).
• Operating temperature range: -20 ºC to +100 ºC (-4 ºF to +212 ºF).
• Construction: 4-conductor, 22 AWG with braided shield and drain wire (85% coverage, minimum), PVC outer jacket, nickel-plated coupling nuts.
• Seal: Connectors provide an IP67 seal to transducers and mating hardware; connectors are molded to the cable.

The IP67-rated connectors protect against dust and water ingress, making the 200151-60-02-10 suitable for harsh industrial settings. The braided shield with 85% minimum coverage ensures excellent noise rejection for accurate signal transmission.

Applications and Use Cases

In predictive maintenance programs, the 200151-60-02-10 connects accelerometers to data collectors or monitoring systems. Its 6.0 meter length provides flexibility for routing in tight machinery spaces while maintaining signal quality.

For example, in a rotating equipment monitoring setup, this cable reliably transmits vibration data from the sensor to the analyzer, helping technicians detect early signs of bearing wear or imbalance. The enhanced coupling nuts reduce the risk of loosening due to vibration, a common failure point in standard cables.

Installation and Setup

When installing the 200151-60-02-10, ensure the cable is routed with a bend radius no smaller than 63.5 mm (2.5 in) to prevent internal damage. The connectors are molded to the cable and provide an IP67 seal when properly tightened to the transducer and mating hardware.

For installations where the cable may flex at temperatures below -20 ºC (-4 ºF), avoid bending or flexing to prevent damage. The addition of DC4 electrical insulating compound in the connectors offers extra moisture protection during thermal shock, but follow the compound's cure time of 24 hours at -55 ºC to +121 ºC (-67 ºF to +250 ºF) before exposing the assembly to full operating conditions.

Maintenance and Reliability

Regular inspection of the 200151-60-02-10 cable and connectors is recommended. Check for cuts, abrasions, or kinks in the PVC jacket, and verify that the coupling nuts remain tight. The nickel-plated coupling nuts resist corrosion, extending service life in humid or corrosive environments.

Because the cable is molded at the connectors, there are no user-serviceable parts. If damage occurs, replace the entire cable assembly to maintain signal integrity and IP67 sealing.

Frequently Asked Questions

What is the length of the 200151-60-02-10 cable?

The cable length is 6.0 meters, indicated by the -60 in the model number.

Does the 200151-60-02-10 include armor?

No, the armor option 02 means it is a blue cable without armor.

What is the minimum bend radius for this cable?

The minimum bend radius is 63.5 mm (2.5 inches).

What temperature range can the 200151-60-02-10 operate in?

The operating temperature range is -20 ºC to +100 ºC (-4 ºF to +212 ºF).

Are the connectors sealed against moisture?

Yes, the connectors provide an IP67 seal and are molded to the cable for added protection.

Product Support and Availability

The 200151-60-02-10 is in stock and ready to ship from Petro Auto Tech. Contact our team for pricing and delivery options. Please verify current lifecycle status and availability with Petro Auto Tech before ordering.
