31000-16-05-15-040-02-02 | Bently Nevada 8 mm Probe Housing

Introduction to the Bently Nevada 31000-16-05-15-040-02-02

When reliable vibration monitoring is critical, the 31000-16-05-15-040-02-02 from Bently Nevada delivers dependable performance. This 31000 proximity probe housing is engineered to protect a 3300 XL 8 mm probe in demanding industrial environments. Therefore, it is a solid choice for machinery protection systems.

This housing is part of the trusted Bently Nevada 31000 series. It is designed for use with the 3300 XL 8 mm probe. Consequently, it helps ensure accurate shaft vibration and position measurements.

Key Features and Technical Specifications

First, the housing is constructed from glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic with conductive fibers. This material provides excellent strength and electrostatic dissipation. Additionally, the sleeve and retaining chain are made of AISI 304 stainless steel. The outer sleeve and exterior screws use AISI 303 stainless steel for corrosion resistance.

• Probe Option: 3300 XL 8 mm probe with connector
• Probe Cable Length: 0.5 m (20 in)
• Standoff Adapter: Minimum length 1.5 in (38 mm)
• Probe Penetration: 4 in
• Mounting Thread: 3/4-14 NPT
• Fittings: Two 3/4-14 NPT fittings, one plug
• Temperature Rating: -51°C to +105°C (-60°F to +221°F)
• Weight: 1.2 kg (2.6 lb)

Moreover, the housing has a Type 4X rating certified by CSA. It also meets IP66 rating verified by SC115582-1 (e) 106. Furthermore, it complies with CENELEC standard EN50014 for electrostatic dissipation of plastic materials in hazardous areas.

Real-World Applications

In rotating machinery monitoring, the 31000-16-05-15-040-02-02 excels. For example, it is suitable for turbines, compressors, and pumps. Consequently, it helps prevent unplanned downtime by providing accurate data. Additionally, its rugged construction makes it ideal for harsh environments. Therefore, it supports predictive maintenance strategies effectively.

Installation and Setup Guidance

When installing this housing, proper mounting is essential. First, ensure the mounting thread (3/4-14 NPT) is clean and compatible. Then, use the recommended torque of 29.4 N·m (260 in·lb) for the retaining nut. This ensures a secure fit. After that, verify the probe cable length (0.5 m) is sufficient for your setup. Finally, check that the standoff adapter is correctly positioned for optimal measurement.

Maintenance and Reliability Tips

Regular inspection of the housing is recommended. Check the O-ring (Neoprene) for wear and replace if necessary. Also, verify that the stainless steel components remain free of corrosion. Consequently, this helps maintain the housing's protective integrity. Moreover, periodic checks of the mounting torque can prevent loosening. Therefore, you can extend the service life of your monitoring system.

Compatibility and Integration

The 31000-16-05-15-040-02-02 is specifically designed for the 3300 XL 8 mm probe. Therefore, it integrates seamlessly with Bently Nevada monitoring systems. This compatibility ensures reliable signal transmission. Additionally, the 3/4-14 NPT mounting thread is a common standard. Hence, it fits many industrial installations.

Common Questions and Troubleshooting

Q: What is the temperature range for this housing?

A: The housing operates from -51°C to +105°C (-60°F to +221°F).

Q: What probe does this housing support?

A: It supports the 3300 XL 8 mm probe with a connector.

Q: What is the mounting thread size?

A: The mounting thread is 3/4-14 NPT.

Q: Is the housing suitable for hazardous areas?

A: Yes, it has a CENELEC EN50014 rating for electrostatic dissipation of plastic materials.

Q: What is the recommended torque for the retaining nut?

A: The recommended torque is 29.4 N·m (260 in·lb).

Product Support and Availability

For more information or to order the 31000-16-05-15-040-02-02, contact Petro Auto Tech. We are ready to assist with your industrial automation needs. Please verify current lifecycle status and availability with Petro Auto Tech before ordering.
