31000-28-10-00-146-00-02 | Bently Nevada 3300 XL 8 mm Probe Housing

Introduction to the 31000-28-10-00-146-00-02

When process machinery faces washdowns, dust, or corrosive atmospheres, standard probe housings often fail prematurely. The 31000-28-10-00-146-00-02 from Bently Nevada addresses this pain point directly. This 31000 Proximity Probe Housing is engineered to seal the differential pressure between the probe tip and the housing main body when used with a 3300 XL 8 mm probe. Its rugged construction and certified protection ratings make it a reliable choice for demanding industrial environments.

Key Features and Technical Specifications

The 31000-28-10-00-146-00-02 offers a range of features that ensure durability and performance. Below are the key specifications extracted from the official datasheet:

• Probe Option: 3300 XL 8 mm probe with connector (multiple approvals)
• Probe Cable Length: 1.0 in
• Standoff Adapter: None
• Probe Penetration: 14.6 in
• Mounting Thread: 3/4-14 NPT
• Housing Material: Glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic with conductive fibers
• Sleeve Material: AISI 304 stainless steel; Outer sleeve and screws: AISI 303 stainless steel
• O-Ring Material: Neoprene®
• Temperature Rating: -51°C to +105°C (-60°F to +221°F)
• Weight: 1.2 kg (2.6 lb)

One distinctive spec is the housing impact strength. Certified by BASEEFA to withstand two separate 4 Joule (3.0 ft·lb) impacts at -39°C and at 115°C, and verified by CSA to withstand a 7 Joule (5.2 ft·lb) impact at ambient temperature. This means the housing can survive accidental tool drops or debris strikes without compromising the probe.

Applications and Use Cases

This housing is ideal for rotating machinery monitoring in industries such as oil and gas, power generation, and chemical processing. For example, in a compressor station, the 31000-28-10-00-146-00-02 protects vibration probes from moisture and dust, ensuring accurate readings. Additionally, its NEMA 4X and IP66 ratings allow installation in areas that require frequent washdowns, such as food processing plants. Furthermore, the housing is suitable for hazardous areas due to its CENELEC EN50014 rating for electrostatic dissipation.

Installation and Mounting Guidance

Proper installation is crucial for optimal performance. The mounting thread is 3/4-14 NPT, which is required if you order a standoff adapter. Ensure the probe cable length of 1.0 in is correctly routed to avoid strain. The recommended torque for the retaining nut is 29.4 N·m (260 in·lb). Always follow the manufacturer's manual for detailed wiring and mounting instructions. If you need a pressure seal test, contact Bently Nevada's custom design department.

Maintenance and Reliability

To maintain reliability, inspect the housing periodically for cracks or damage, especially after impact events. Check the O-rings for wear and replace them if necessary. The stainless steel sleeves resist corrosion, but regular cleaning with mild detergent is recommended. Because the housing is not designed to resist internal or external pressure, avoid pressurizing the enclosure. Following these practices extends the service life and reduces downtime.

Compatibility and Integration

The 31000-28-10-00-146-00-02 is designed specifically for Bently Nevada 3300 XL 8 mm probes. It integrates seamlessly with Bently Nevada monitoring systems. The housing includes a connector option, making it easy to connect to existing cabling. For detailed compatibility information, refer to the official Bently Nevada documentation.

Troubleshooting Common Issues

If you experience signal loss, first check the probe cable connection. Ensure the cable length is 1.0 in and not stretched. If the housing is exposed to extreme temperatures, verify it is within the -51°C to +105°C range. For electrostatic discharge concerns, the conductive PPS material provides dissipation. If problems persist, consult the Bently Nevada manual or contact Petro Auto Tech for support.

FAQ about the 31000-28-10-00-146-00-02

Q: What is the temperature rating of the 31000-28-10-00-146-00-02?

A: The housing is rated for -51°C to +105°C (-60°F to +221°F), ensuring operation in extreme conditions.

Q: What mounting thread does this housing use?

A: It uses a 3/4-14 NPT thread, which is required if you order a standoff adapter.

Q: Is the housing suitable for hazardous areas?

A: Yes, it has a CENELEC EN50014 rating for electrostatic dissipation of plastic material in hazardous areas.

Q: What is the weight of the housing?

A: The housing weighs approximately 1.2 kg (2.6 lb).

Product Support and Availability

The 31000-28-10-00-146-00-02 is available through Petro Auto Tech. Contact us for current stock and lead times. We are ready to assist with your order.
