Allen-Bradley 1747-M13 SLC 500 Memory Module 64KB

Product Overview

The Allen-Bradley 1747-M13 is a memory module for SLC 500 systems. It stores 64 kilobytes of user data. This module uses Flash memory. It works with SLC 5/03, 5/04, and 5/05 processors. The module protects programs if the backup battery drains. It loads data automatically at startup. Use it with a 1747-M13 memory adapter (series B). This prevents damage and ensures reliable operation.

Application Scenarios

This module fits fixed or modular SLC 500 chassis. It is ideal for critical processes. Factories use it to avoid unplanned shutdowns. It works in 3-chassis systems with up to 30 slots. The module supports Ethernet and RS-232 communication. It is perfect for backup memory in remote or battery-critical sites.

Technical Specifications

• Memory: 64 kilobytes (64,000 words)
• Type: Flash
• Scan time: 0.9 ms program, 0.225 ms I/O
• Compatible processors: SLC 5/03, 5/04, 5/05
• Adapter required: 1747-M15 series B
• UPC: 10662468232910

Installation & Maintenance Guide

Turn off the controller before installation. Orient the module correctly on jumpers. Connect jumper A18 to center pin. Use only a series B adapter. Never expose the module to static discharge. Static can destroy the memory. The connectors are keyed to prevent wrong insertion. After fitting, the program burns automatically on power cycle.

Packing List

• 1x Allen-Bradley 1747-M13 Memory Module
• Installation instructions

Shipping via FedEx, UPS, or DHL.
