Allen-Bradley 1756-L64 ControlLogix Processor 16MB

Product Overview

The Allen-Bradley 1756-L64 processor is part of the ControlLogix family. It delivers high-speed processing for complex automation systems. This module features 16 MB of user memory. It handles up to 128,000 digital I-O points. The 1756-L64 supports 4,000 analog I-O channels. Its robust design ensures reliable operation in harsh environments. This processor uses a 32-bit backplane. It integrates seamlessly with other ControlLogix modules. The unit requires 1200 mA at 5.1 Volts DC. It also draws 14 mA at 24 Volts DC. Total power dissipation is just 3.5 Watts. This keeps your control cabinet cool.

Application Scenarios

This processor excels in discrete manufacturing lines. It controls assembly stations and packaging machinery. The 1756-L64 works well in process industries. It manages batch control and continuous processes. Use it for material handling systems. It coordinates conveyors and sortation equipment. The module suits oil and gas applications. It handles pipeline monitoring and control. Power generation plants benefit from its speed. It manages turbine controls and auxiliary systems. The 1756-L64 fits water treatment facilities. It automates filtration and chemical dosing. Its large memory supports complex programs. It handles data logging and recipe management.

Technical Specifications

The 1756-L64 operates at 0 to 60 degrees Celsius. It can be stored at -40 to 85 degrees Celsius. The module withstands 2 g of vibration. It handles 30 g of operating shock. Non-operating shock tolerance is 50 g. The processor supports 250 maximum controller connections. It has 478 Kilobytes of I-O memory. The isolation voltage is 30 Volts Continuous. Thermal dissipation equals 11.9 BTU per hour. The enclosure type is None (open style). This module uses standard ControlLogix firmware. It supports both digital and analog I-O configurations. The processor communicates via ControlNet or EtherNet/IP.

Installation & Maintenance Guide

Install the 1756-L64 into a ControlLogix chassis. Ensure the chassis is properly grounded. Insert the module into any available slot. Secure it with the locking screws. Connect the backplane cable if required. Power up the system and check the status LEDs. The OK LED should be solid green. Use RSLogix 5000 for configuration. Assign the processor a unique node number. Download your control program to the module. Perform regular firmware updates. Keep the module free from dust. Check connections during routine maintenance. Monitor the processor for fault codes. Replace the module if the FAULT LED stays red. Always follow Rockwell Automation safety guidelines.

Packing List

1 x Allen-Bradley 1756-L64 ControlLogix Processor
1 x Installation Instructions Manual
1 x Product Documentation CD
Shipping: This item ships via FedEx, UPS, or DHL.
