Allen-Bradley 1756-PH75 ControlLogix 125V DC Power Supply

Product Overview

The Allen-Bradley 1756-PH75 is a standard DC power supply module. It belongs to the ControlLogix family. This unit provides stable power to your chassis. It accepts a 125V DC input. The voltage range is 90 to 143V DC. It delivers 13 amps at 5 volts. This power supply is ideal for industrial control systems. It ensures reliable operation for your automation tasks.

Application Scenarios

This power supply works with several chassis models. Use it with the 1756-A4, 1756-A7, or 1756-A10. It also fits the 1756-A13 and 1756-A17 chassis. You can install it in any slot on the left side. It powers the backplane and connected modules. This unit is common in manufacturing plants. It also appears in process control environments. It supports heavy industrial applications.

Technical Specifications

The input power rating is 95 watts. The output power is 75 watts at 60 Celsius. It has a current surge of 30 amps. The isolation voltage is 250V. It uses reinforced insulation tested at 3500V DC. The wire size is 2.5 mm² stranded or solid copper. The conductor torque is 0.8 N·m. The operating temperature range is 0 to 60 Celsius. It can handle a shock of 30G during operation. The vibration tolerance is 2G.

Installation & Maintenance Guide

Install the module in the leftmost slot of the chassis. Use copper wire with 1.2 mm thick insulation. The insulation must be rated for 90 Celsius. Tighten the wires to 0.8 N·m torque. Do not expose the unit to condensation. Keep the relative humidity below 95 percent. Store the unit in a clean, dry area. The storage temperature range is -40 to 85 Celsius. Always follow standard safety procedures.

Packing List

You will receive one Allen-Bradley 1756-PH75 power supply module. It comes with the necessary documentation. The package includes a quick start guide. No additional cables are included. The unit is securely packed for shipping. We ship via FedEx, UPS, or DHL. Delivery is fast and reliable.
