PLC Controller Allen-Bradley 1769-L30 CompactLogix Processor

Product Overview

The Allen-Bradley 1769-L30 is a CompactLogix processor module. It offers 256 Kbytes of user memory. This unit supports up to 16 I/O modules. It can use up to three I/O banks. Each bank needs its own power supply. The module has two RS-232 communication ports. It supports DH485, DF1, and ASCII protocols. A 1 GB non-volatile memory card ships with the controller. The 1769-L30 features a key switch for operation control. The switch offers RUN, PROG, and REM modes.

Application Scenarios

This controller works well in many industrial areas. It is ideal for machine control tasks. It can manage discrete and process applications. The module fits in small control panels. It works with other CompactLogix components. Use it for packaging, material handling, or assembly lines. The built-in Ethernet ports support linear and DLR topologies. This makes it suitable for networked factory systems.

Technical Specifications

The 1769-L30 draws 800 mA at +5V DC on the backplane. It operates from 0 to 60 degrees Celsius. The unit handles 5% to 95% non-condensing humidity. It resists vibration up to 10G at 500 Hz. The shock rating is 30G. Dimensions are 118 mm by 50 mm by 87 mm. It weighs 360 grams. The module uses a 1747-BA battery. It has 1 kV galvanic surge immunity. The unit meets IEC61000-4-5 and IEC61000-4-6 standards. It uses copper wire rated for 90 degrees Celsius.

Installation & Maintenance Guide

Mount the 1769-L30 on a panel or DIN rail. Use a 1747-CP3 or 1756-CP3 cable for programming. Connect the processor to I/O banks with expansion cables. Each bank requires its own power supply. Replace the battery with a 1747-BA type only. Use the 1769-RTBN18 replacement terminal block. Keep the unit within the specified temperature range. Ensure proper ventilation for reliable operation.

Packing List

The package includes one 1769-L30 processor module. It also includes a 1784-SD1 memory card. A programming cable is not included. Order a 1747-CP3 or 1756-CP3 cable separately. The terminal block is sold separately. Use part number 1769-RTBN18 for the terminal block.
