Introducing the 1746-IB16: A Trusted SLC 500 Solution
When designing or upgrading a control system, selecting the right input module ensures reliable data acquisition. The Allen-Bradley 1746-IB16 is a digital DC sinking input module from the SLC 500 series, offering 16 discrete input channels. It operates at a nominal 24VDC with a voltage range of 10-30VDC, making it suitable for various industrial environments.
Technical Specifications Analysis
The 1746-IB16 draws a backplane current of 0.050 A at 5VDC, ensuring low power consumption within the chassis. Each input channel has a nominal input current of 8mA at 24VDC, with a signal delay of 8 ms for both ON and OFF transitions. The module also features a maximum OFF-state voltage of 5.0V DC and a maximum OFF-state current of 1 mA, providing clear signal differentiation.
Application Scenarios and Use Cases
In a packaging line, the 1746-IB16 can monitor the status of multiple limit switches and proximity sensors, feeding real-time data to the SLC 500 controller. For material handling systems, it reliably detects the presence of items on conveyors, ensuring smooth sorting and routing. Its sinking configuration simplifies wiring with common DC sensors.
Compatibility and Integration
The 1746-IB16 is compatible with any SLC 500 chassis, supporting local or distributed I/O configurations via communication adapters. It uses 1746-HT and 1746-HCA I/O connection cables for secure termination. The module's single group of 16 inputs shares a common terminal, streamlining installation.
Market Impact and Business Value
By providing consistent signal detection and low backplane current draw, the 1746-IB16 helps reduce overall system power consumption and maintenance needs. Its robust design minimizes false triggers, improving process uptime. For facilities running legacy SLC 500 systems, this module offers a reliable path to maintain production efficiency without a full migration.
Company Strength and Supply Assurance
Petro Auto Tech specializes in industrial automation parts, offering genuine Allen-Bradley modules like the 1746-IB16. Our team provides expert support to help you select the right components for your application. Please verify current lifecycle status and availability with Petro Auto Tech before ordering.
Frequently Asked Questions About the 1746-IB16
What is the input voltage range for the 1746-IB16? The module operates with a nominal input voltage of 24VDC and an operating voltage range of 10-30VDC, as specified in the technical data.
How many input channels does the 1746-IB16 have? It features 16 discrete sinking input channels grouped into one group with a single common terminal, suitable for monitoring multiple field devices.
What is the signal delay for the 1746-IB16? The signal delay for both ON and OFF transitions is 8 ms, ensuring timely data capture for control logic.
Can the 1746-IB16 be used in a distributed I/O configuration? Yes, it can be installed in a distributed I/O chassis with a 1746 communication adapter, such as Remote I/O or Ethernet adapter modules.
What is the backplane current draw of the 1746-IB16? The module draws 0.050 A at 5VDC from the backplane, contributing to low overall system power consumption.
