Product Summary
The 1771-CE is a compact I/O chassis cable from the Allen Bradley PLC 5 series. This 1-foot (0.3 m) cable ensures a dependable connection between your chassis and the 1771-P2 power supply. Its 9-pin male and female plugs provide a secure link for control systems.
Why the 1771-CE Fits Your Procurement Needs
Optimizing Your Panel Layout
This cable measures exactly 1 foot in length. This size helps you manage cable runs within tight control panels. You avoid excessive slack that can hinder airflow.
Ensuring System Compatibility
The 1771-CE works specifically with the 1771-P2 power supply. This pairing creates a stable electrical path. You guarantee reliable power delivery to your I/O modules.
Evaluating Physical Specifications
This cable weighs only 1.06 pounds (0.48 kg). This lightweight design eases integration into existing assemblies. It adds minimal strain to your mounting points.
Understanding Connector Architecture
The cable uses both male and female plug connectors. It includes 9 pins for robust connectivity. This design prevents signal loss during critical operations.
Reviewing Environmental Tolerances
The unit operates from 0 to 60°C. You can store it safely between -40 and 85°C. This range suits many demanding industrial environments.
Assessing Electrical Performance
This cable functions at 50 to 60 Hertz. It also withstands 5% to 95% humidity without condensation. These specs confirm its reliability for diverse applications.
Expert Technical Evaluation of the 1771-CE
Mechanical Construction and Durability
The 1771-CE uses robust male and female plug connectors. The 9-pin design creates a tight physical lock. This prevents accidental disconnection from vibration.
Signal Integrity for Your Application
The cable provides a secure shielded path for signals. Its short 1-foot length minimizes electrical noise interference. You maintain clean data transfer between components.
Thermal Management Capabilities
The unit handles a wide operating temperature window. It works between 0 and 60°C without performance loss. This thermal range supports most factory floor settings.
Resilience Against Moisture
You can use this cable in high-humidity environments. It tolerates humidity levels from 5% to 95% without condensation. This protects your system in washdown areas.
Frequency Response and Power Handling
The cable supports a standard line frequency of 50 to 60 Hertz. This makes it suitable for global power systems. It reliably handles the power from the 1771-P2 supply.
