The Allen-Bradley 1768-EWEB Enhanced Web Server module empowers plant managers with secure remote access to control system data. This CompactLogix module collects information over a single high-speed EtherNet/IP network. It creates intuitive XML web pages for real-time monitoring and modification of industrial processes.
Product Procurement & Buyer Guide
Core Network Connectivity
The 1768-EWEB uses a single RJ45 Category 5 interface to communicate at 10/100 Mbps. It supports up to 64 TCP/IP connections and 128 CIP connections simultaneously. This robust capacity ensures seamless data exchange across your plant network.
Storage and Data Handling
The module contains a flash file system with 2 MB of dedicated storage for web pages and data views. This capacity allows engineers to host customized monitoring pages directly on the module. You can store multiple dashboard layouts without external servers.
Physical Installation and Mounting
The device weighs approximately 7.5 ounces and ships with dimensions of 8 x 8 x 5 inches. You can panel mount the module or install it onto a DIN rail. It fits into slot 3 or slot 4 of the CompactLogix 1768 bus. This flexibility simplifies integration into existing control cabinets.
Electrical Requirements and Isolation
The 1768-EWEB consumes only 4.34 Watts of power during normal operation. It provides an isolation voltage of 30 Volts to protect sensitive components. These specs make it suitable for electrically noisy industrial environments.
Compatibility and Series Options
This module comes in Series A and B, both backward compatible with the 1769-L45 controller. It uses 802.3 compliant shielded or unshielded twisted-pair cable. The unit operates without an enclosure, reducing installation costs for plant managers.
