Product Summary
The Flexem FR-T0400P temperature acquisition module delivers reliable multi-sensor monitoring for industrial automation. This unit supports PT100, PT1000, Ni100, Ni1000, Cu50, and Cu100 sensors across wide ranges. It achieves a measurement accuracy of ±0.5% or ±1°C, whichever value is greater. Engineers will appreciate its ultra-compact 18mm width and low power consumption.
Expert Technical Evaluation & Performance Review
This module provides a robust solution for precise temperature data logging. It accepts four input channels for various resistance temperature detectors. The FR-T0400P handles PT100 sensors from -200°C up to 850°C with excellent linearity. It also supports PT1000 probes for applications requiring -200°C to 600°C. You can deploy Ni100 sensors for ranges between -60°C and 180°C. The unit also works with Cu50 and Cu100 sensors for specific industrial needs. Each channel delivers consistent accuracy across the entire operating spectrum. The module draws a maximum of only 50mA from a 5.0Vdc supply. This low power draw makes it ideal for distributed I/O cabinets. Its lightweight 65g frame simplifies mounting on standard DIN rails. The compact dimensions of 111x18x76 mm save valuable panel space. Engineers can rely on this module for long-term, drift-free temperature monitoring.
Deep-Dive Technical FAQ
What sensor types does the FR-T0400P support for temperature measurement?
This module supports PT100, PT1000, Ni100, Ni1000, Cu50, and Cu100 sensors. Each channel can independently connect to any of these RTD types.
What is the maximum temperature range for a PT100 sensor on this module?
The FR-T0400P measures PT100 sensors across a very wide range from -200°C to 850°C. This covers most high-temperature industrial process requirements.
How does the module determine its measurement accuracy specification?
Accuracy is stated as ±0.5% of reading or ±1°C, whichever value is larger. This specification applies at a 25°C ambient temperature.
What is the physical size and mounting requirement for this device?
The module measures 111mm in height, 18mm in width, and 76mm in depth. It weighs only 65 grams and fits standard industrial enclosures.
What is the power consumption characteristic of the FR-T0400P?
This temperature acquisition module consumes a maximum of 50mA at 5.0Vdc. This low power requirement simplifies your system power budget calculations.
