Product Overview

The 2094-BC02-M02-S is an Allen-Bradley Kinetix 6000 Integrated Axis Module (IAM) designed for 400 Volt Class applications. This Rockwell Automation module delivers high efficiency and robust performance for demanding industrial motion control systems.

Technical Specifications Analysis

This IAM operates with an AC input voltage of 324 to 528 Volts RMS 3 Phase (360 to 480 Volts nom) and an AC input frequency of 47 to 63 Hertz. It provides a nominal RMS AC input current of 24.0 Amps and a maximum inrush current of 22.0 Amps. The DC input voltage ranges from 458 to 747 Volts with a DC input current of 22.6 Amps. The module achieves an efficiency of 97% and includes an internal shunt resistor of 115 Ohms with continuous power of 50 Watts and peak power of 5.6 Kilowatts. It weighs 11.2 pounds (5.08 kilograms).

Application Scenarios & Usage Methods

Integrate the 2094-BC02-M02-S into multi-axis servo systems for packaging, printing, or material handling. Use it as a common bus follower to share DC power across multiple axes, reducing energy costs. The Safe-Torque Off function enhances safety during maintenance or emergency stops.

Installation Guide & Packing List

Mount the module in a clean, ventilated cabinet. Ensure AC input voltage matches 324-528VAC 3-phase and DC bus connections are secure. The package includes the 2094-BC02-M02-S module only. Refer to the Kinetix 6000 installation manual for detailed wiring and configuration.

Purchasing Advice

Verify your system voltage and current requirements against the 2094-BC02-M02-S specs. For high-torque applications, consider the peak current capabilities. Petro Auto Tech offers genuine Allen-Bradley modules with fast shipping and expert support.

Repair & Maintenance Tips

Periodically check for dust buildup on heatsinks and ensure cooling fans operate. Inspect DC bus connections for tightness. Test Safe-Torque Off functionality regularly. Store in a dry, static-free environment.

Frequently Asked Questions (FAQs)

Q: What is the AC input voltage range for the 2094-BC02-M02-S?

A: The AC input voltage is 324 to 528 Volts RMS 3 Phase (360 to 480 Volts nom).

Q: Does this module support Safe-Torque Off?

A: Yes, the 2094-BC02-M02-S includes Safe-Torque Off functionality for enhanced safety.

Q: What is the efficiency of this IAM?

A: The module achieves an efficiency of 97%.

Q: What is the weight of the 2094-BC02-M02-S?

A: It weighs 11.2 pounds (5.08 kilograms).
