Discrete Output Module Allen-Bradley 1762-OA8 AC Triac Output

Product Overview

The Allen-Bradley 1762-OA8 is a solid-state output module. It provides 8 AC triac outputs. It operates on 85 to 265 Volts AC. This module is designed for MicroLogix systems. It delivers reliable on-off control. The compact size saves panel space. It dissipates only 2.9 Watts of heat. The module weighs just 0.5 pounds.

Application Scenarios

Use the 1762-OA8 in various industrial automation tasks. Control motors, valves, and solenoids. Switch lights and heaters. Manage conveyor systems. It works with mechanical and solid-state loads. This module is ideal for factory floor equipment. It also fits building automation systems. Use it with PLC systems that need multiple AC outputs.

Technical Specifications

• Manufacturer: Rockwell Automation
• Brand: Allen-Bradley
• Part Number: 1762-OA8
• Function: Solid-State Output Module
• Input Power: 100 to 240 Volts AC
• Outputs: 8 AC Triac
• Dimensions (HxWxD): 3.54 x 1.59 x 3.43 inches
• Shipping Weight: 0.5 pounds
• Heat Dissipation: 2.9 Watts
• Operating Voltage: 85 to 265 Volts AC
• Operating Frequency: 47 to 63 Hertz
• Commons: 2
• Maximum Bus Current: 115 mA at 5 Volts DC
• Maximum Voltage Drop: 1.5 Volts at 0.5 Amps
• Minimum On-State Current: 10 mA
• Operating Temperature: 32 to 131 degrees Fahrenheit
• Non-Operating Temperature: -40 to 185 degrees Fahrenheit
• Standards: NEMA ICS 2-230, EN50081-2 Class A, IEC1000-4-2, IEC1000-4-3

Installation & Maintenance Guide

Mount the module on a grounded metal panel. Keep the finger-safe cover in place during wiring. Remove cover only after wiring is complete. The cover cannot be reinstalled once removed. Ensure no metal fragments remain inside the module. Fragments can cause damage when power is applied. Follow Allen-Bradley wiring and grounding guidelines. The 1762-OA8 is compatible with MicroLogix 1100, 1200, and 1400 systems. Use proper wire gauges and torque settings. Check all connections before applying power. Perform periodic inspections for dust or damage. Replace the module if any signs of failure appear.

Packing List

• 1 x Allen-Bradley 1762-OA8 solid-state output module
• 1 x Terminal block (installed)
• 1 x Quick reference guide
