Product Summary
The 1734-IB4 delivers four sinking input channels for 12/24V DC sensors in a compact DIN-rail mountable design. This module integrates seamlessly with any 1734 POINT I/O communication adapter to implement cost-effective distributed I/O architectures for PLC-based automation systems.
Why Choose the 1734-IB4 for Your Procurement List
Procurement managers value the 1734-IB4 for its ultra-compact footprint (56 x 12 x 75.5 mm) that saves valuable panel space. This low-density module eliminates over-provisioning in small-scale applications.
The module supports both two-wire and three-wire sensor signals. This flexibility reduces your inventory complexity and simplifies panel wiring.
With a nominal input voltage of 24V DC and an operating range from 10 to 28.8V DC, this unit matches standard industrial supplies. Its input current stays at a maximum of 5 mA per channel, ensuring low power consumption.
Power dissipation is merely 1W (3.4 BTU/hr). This low thermal output allows dense stacking without extra cooling, lowering your overall system cost.
The module draws only 75 mA from the POINTBus at 5V DC. Communication adapters easily power multiple modules on the same bus.
Each channel includes a user-selectable input filter from 0.5 ms hardware plus 0 to 63 ms software. You can tune noise immunity without sacrificing response time.
Four yellow LED indicators show Input 0–3 status clearly. Network and Module status LEDs provide immediate fault diagnostics, reducing downtime.
Step-by-Step Installation Guide
Mount the 1734-IB4 on a zinc-plated, yellow chromate steel DIN rail. Never use aluminum or plastic rails as they may corrode and cause poor grounding.
Secure the DIN rail every 200 mm using appropriate anchors. This ensures stable mechanical support for the module and adjacent I/O blocks.
Orient the module with its removable terminal block (RTB) at the bottom. Connect field wiring to the RTB before snapping it onto the module.
Wire your sinking input sensors to the proper terminals. Use 24V DC field power; the module accepts 10–28.8V DC.
Set the keyswitch position to 1 (factory default) to prevent incorrect module insertion. Write the node address in the writable area on the front panel for easy identification.
Power up the system through the communication adapter. The POINTBus automatically provides 5V DC to the module circuitry.
