Allen-Bradley PowerFlex 4M 22F-D6P0N103 3 HP AC Drive

Product Overview

The Allen-Bradley PowerFlex 4M drive offers a simple solution for motor control. This model, the 22F-D6P0N103, provides 3.0 HP of output power. It operates on a 380-480VAC, 3-Phase input. The drive delivers an output current of 6.0 Amps. Its compact frame size B saves valuable panel space. The integrated Human Interface Module allows for easy local programming. This unit uses Volts per Hertz (V/Hz) control. It is ideal for basic speed control applications.

Application Scenarios

This drive works well for many standard industrial machines. Use it for conveyors, fans, and pumps. It also works for simple material handling equipment. The IP20 enclosure suits indoor panel mounting. The integrated RS485 port enables simple network communication. You can add optional protocols like EtherNet/IP. This flexibility makes it fit into different plant networks.

Technical Specifications

The 22F-D6P0N103 has five discrete sink/source inputs. It has one Form C relay output. It includes one analog input for 4-20 mA. It also has one analog input for 0-10VDC. The unit measures 3.94 x 6.85 x 5.35 inches. It weighs only 4.6 pounds. The maximum ambient temperature is 50 degrees Celsius. The unit has a built-in RS485 port. It does not include a CE compliant filter. The unit supports V/Hz and Sinusoidal PWM control methods.

Installation & Maintenance Guide

Mount the drive on a flat, vertical panel. Ensure proper airflow for cooling. Do not block the ventilation slots. Use copper conductors rated for 75 degrees Celsius. Follow the torque specifications in the manual. Perform routine inspections for dust buildup. Check all power connections for tightness. Always disconnect power before servicing the unit.

Packing List

One Allen-Bradley PowerFlex 4M AC Drive. One quick start guide. One installation manual. No additional cables or software are included. All items are securely packed for shipping. We ship via Fedex, UPS, or DHL.
